2 PRESENTATION
2.2.3.5 Example of an Input window
16 (128)
Use the navigation keys
you want to change using the Right and Left arrows. Use the Up
and Down arrows to change a number. Save by pressing
To enter a name, select the desired letter using the cursor keys
and press to select the letter. Select the back arrow, furthest to
the right, and press to cancel the entry. To toggle between lower
case and capital letters, select the up arrow furthest to the left and
press .
To switch to a numerical keyboard, select the box with numbers
furthest to the left and press
Save the entry by selecting
There are various entry windows depending on the input data
required.
In addition to plain text, a number of different symbols (as
described in the table below) are used in the window.
Function Symbol
Process handling
Program
Start
Alarm management
Alarms
Miscellaneous
Save
Numerical
keyboard
TECHNICAL MANUAL GETINGE WD15 CLARO
to edit the value. Select the digit that
.
furthest to the left and pressing
Description
Open the menu to choose a
program.
Start the selected program.
An alarm symbol displays if an
alarm goes off and is not yet
acknowledged.
Save changes and entered
values.
Shift from alphabetical to
numerical keyboard.
.
.
