Getinge WD15 CLARO Technical Manual page 25

3.2.3.1 Setting
3.2.3.1.1 Date and time
3.2.3.1.2 Machine setup
TECHNICAL MANUAL GETINGE WD15 CLARO
In this menu the operator can make the following settings:
• Date and time
• Machine setup
• Machine name
• Panel setup
• Communication
• Localization
• Printer setup
• Alarm clock
• Screen setup
Select the field that will be edited and press
A window is displayed where the selected field can be edited. Edit
by using the cursor keys.
Press to save the change. The previous window is displayed
again.
Select the key at the bottom of the list and press
the settings.
A list of the system's available machine functions is shown.
The machine functions can be turned on or off by highlighting the
desired machine function and pressing
Select at the bottom of the list and press
settings.
When the settings are saved a popup window is shown, giving you
the option of printing out the machine settings.
3 MENU TREE
.
to save
to change the value.
to save the
25 (128)
