4x2 HDMI 2.0 Matrix Switcher with Audio
Extract/Scale/ARC/EDID function
VER 1.1
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please keep this
manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the
life of your equipment.
Table of Contents

Advertisement

loading

Related Manuals for BZBGEAR BZBGEAR

Summary of Contents for BZBGEAR BZBGEAR

  • Page 1 4x2 HDMI 2.0 Matrix Switcher with Audio Extract/Scale/ARC/EDID function VER 1.1 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.

  • Page 2: Table Of Contents

    1. Introduction 2. Features 3 3. Package Contents 4. Specifications 5. Operation Controls and Functions 5 5.1 Front Panel 5.2 Rear Panel 7 6. IR Remote 7. Application Example 11 8. FAQ 1. Introduction This high performance HDMI Matrix Switcher can switch any of four HDMI sources to two HDMI displays.

  • Page 3: Specifications

    4. Specifications Technical HDMI Compliance HDMI 2.0 HDCP Compliance HDCP 2.2 and HDCP 1.4 Video Bandwidth 18 Gbps Video Resolution Up to 4K2K@50/60Hz(YCbCr 4:4:4),4K2K@30Hz.All HDMI 3D TV format, etc. Color Space RGB, YCbCr4:4:4,YCbCr4:2:2, YCbCr 4:2:0 Color Depth 8-bit, 10-bit, 12-bit [1080P, 4K30Hz, 4K60Hz (YCbCr 4:2:0)] 8-bit [4K60Hz (YCbCr4:4:4)] HDMI Audio Formats PCM2.0/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD,...

  • Page 4: Operation Controls And Functions

    Dimensions 251mm(W)×105mm(D)×20mm(H) Weight 620g Power Supply Input: AC100~240V 50/60Hz Output: DC12V/1A Power Consumption 3.8W (max) Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F Relative Humidity 20~90% RH (non-condensing) 5. Operation Controls and Functions 5.1 Front Panel Number Name...

  • Page 5: Rear Panel

    a few HDMI IN ports are connected source device, OUT A port will output the signal from the last connected input source. OUT B button and LED Press the OUT B button to select an input source to OUT B output, the corresponding blue LED will illuminate.

  • Page 6: Ir Remote

    HDMI IN port HDMI input ports, connect to HDMI source device such as DVD or PS4 with an HDMI cable. HDMI OUT A / OUT B port HDMI output ports, connect to HDMI display device such as TV or Monitor with an HDMI cable.
  • Page 7 Output A 1/2/3/4 Select input source signal to Out A port output, the corresponding blue LED on the front panel will illuminate. Select the last or next input source signal to OUT A port output, the corresponding blue LED on the front panel will illuminate.

  • Page 8: Application Example 11

    source audio from Out A port or Out B port to optical port (TOSLINK) and analog L/ R port (Audio out) output. 7. Application Example 8. FAQ 1. Q: Does this product require an HDMI line length for the connection interface? A: According to HDMI line length test, HDMI input / output with 4K60Hz YCbCr 4:4:4 is the longest line length up to 8m / 3m.
  • Page 9 Taking advantage of this program is simple, just follow the steps below: 1. Register your product within 90 days of purchase by visiting BZBGear.com/ warranty. 2. Complete the registration form. Provide all necessary proof of purchase details, including serial number and a copy of your sales receipt.
