Wall Box
Metal Bracket
Mounting the Bracket to an EU Wall Box
Figure 5.
Place the bracket against the box, aligning the holes in the bracket with the corresponding threaded holes on the edges
b.
of the box.
Insert the provided screws into those holes, hold the bracket to ensure it is aligned straight (visually level), and tighten
c.
the screws to secure the bracket to the mounting surface.
Step 3: Change Buttons (optional)
If desired, replace one or more buttons or button pairs using available additional buttons. Optional button kits are available in
various languages.
NOTE: A custom button builder tool is available at
where you can order custom-labeled buttons for the MLC Plus 84.
The faceplates must be removed to access buttons. To replace the buttons:
Remove one or both faceplates as follows:
1.
Slide the
a.
center divider
bar up
(as shown in
figure 7) and
remove it
from the unit.
Set it aside
for later
use.
L A
S P
D I
O N
P C
O P
P T
L A
1
M I
H D
Removing the Center Divider
Figure 7.
http://www.extron.com/product/custombuttonbuilder/index.aspx
Y
F
O F
C
D O
M
C A
O P
P T
L A
2
A
V G
External Wall Box
Metal Bracket
Mounting the Bracket to an MK Wall Box
Figure 6.
If removing the volume control faceplate, remove the
b.
volume control knob as follows:
Y
L A
S P
D I
F
O F
O N
C
D O
M
C A
P C
P
T O
L A P
2
P
T O
L A P
2
1
M I
H D
1
M I
H D
Loosening the Set Screw to Remove
Figure 8.
the Volume Knob
Viewing the unit from the bottom, look through the
1.
faceplate notch below the Volume knob and rotate
Notch
