Cosec Path As A Reader - Matrix COSEC PATH DCFE Quick Installation Manual

1
Black
GND
RS232 TX Grey
Rs232 RX
Pink
GND Black
TMPR NC/NO Light Blue
W DATA1 White
W DATA0 Green
6
Blue
HOLD
BEEPER
Yellow
ALARM Violet
STATUS Light Brown
RED LED Brown
GREEN LED Orange
GND Black
+12VRDR Red
1
RS-485 A Blue
Brown
RS-485 B
7
Yellow
SHLD
+12VRDR White
GND Black
9
COSEC PATH as a Reader (RDF /RDC )
To Any COSEC Door Controller
COSEC ARC
To COSEC ARC Controller
X X
1
RS-485 1
6
7
Reset
COSEC PATH RDF /RDC (Rear View) X X
10
