Cosec Path As A Door Controller - Matrix COSEC PATH DCFE Quick Installation Manual

1
Black
GND
RS232 TX Grey
Rs232 RX
Pink
GND Black
TMPR NC/NO
Light Blue
W DATA1
White
W DATA0 Green
5
Blue
HOLD
BEEPER Yellow
ALARM Violet
STATUS Light Brown
RED LED Brown
GREEN LED Orange
GND Black
+12VRDR Red
Panel200
7
COSEC PATH as a Door Controller (DCF /DCC )
To External Reader
5
1
4
Exit Switch
Exit
1
Reset
1
RS-485
RS-485 A Blue
Brown
RS-485 B
4
SHLD Yellow
EXIT SW White
Black
GND
DC Power Jack
Mounting Hook
1
1
1
2
1
3
1
RJ-45 Plug
COSEC PATH DCF /DCC (Rear View)
X X
DC 12V
Power Supply
1
Using 12VDC of the Door
12V/24V
+12V LOCK
GND
RLY NC
RLY COM
EM Lock
2
Using External Power Supply
RLY NC
RLY COM
EM Lock
3
Ethernet Cable
X X
1
PWR GND Black
+12VDC IN Red
1
+12V LOCK Red
+12V LOCK Red
GND Black
GND Black
DOOR STS White
Black
GND
RLY NC Blue
RLY COM Brown
Yellow
RLY NO
Light Blue
GND
1
TX- Light Brown
TX+ Brown
Light Blue
RX-
RX+ Blue
COM1 Green
Green
COM1
COM2 Yellow
COM2 Yellow
8
