SATATYA Network PTZ Controller (NPC430)
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SATATYA NPC430 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Matrix SATATYA NPC430

Summary of Contents for Matrix SATATYA NPC430

  • Page 1 SATATYA Network PTZ Controller (NPC430) User Guide...
  • Page 2 Please read this guide first for correct installation and retain it for future reference. The information in this guide is prevailing at the time of publication. However, Matrix Comsec reserves the right to make changes in product design and specifications without prior notice.
  • Page 3 Preface Thank you very much for purchasing our products. Please be free to contact us if there is any questions or requirements. The purpose of this manual is to ensure that the user can use the product correctly to avoid danger or property damage during operation.

  • Page 4: Table Of Contents

    Contents Product Description .................... 6 Description ..................... 6 Product Features ..................6 Product interface ....................7 Interface Description ................7 System expansion diagram ..............8 Button Description ....................9 Function key area description ..............9 Network PTZ Controller rotations description ........11 Device addition and deletion ................
  • Page 5 Import Configuration ................18 Export Configuration ................19 Disposal of Products/Components after End-Of-Life ......... 21 E-Waste Management and Handling Rules ............23 E-Waste Management Plan ................26...

  • Page 6: Product Description

    Product Description Description The Network PTZ Controller has used industrial-grade LCD modules for displaying better. Support standard Onvif protocol and pelco protocol, good compatibility and scalability. The built-in web server makes the configuration interface simple and clear. It is easy to install and operate.

  • Page 7: Product Interface

    Product interface Interface Description Power switch RS422 RS232 Power interface...

  • Page 8: System Expansion Diagram

    Number Name Function Power on/off Power swtich Power 12V, 2A (Same specs like our IPC) Connect network Support visca RS232 Support pelco RS422 System expansion diagram (1) Network connection Network mode network VISCA, ONVIF control camera connection diagram Camera and keyboard need to be connected to the same LAN, and ensure that the IP address is in the same network segment, such as: 192.168.1.126 and 192.168.1.120 belong to the same network segment;...

  • Page 9: Button Description

    (2) Analog mode RS 485 control camera connection diagram . Control output: The RS485+ of the camera is connected to Ta of the controller, and the RS485- of the camera is connected to the Tb of the controller. Button Description Function key area description...
  • Page 10 Enter the keyboard settings interface Settings Search Network mode can search online camera, analog equipment mode this button is invalid Setting Manually add equipment Manual Add Area List of devices View device information stored on the keyboard Move the camera to the desired location, press this key, Presets enter the number, press confirm to set the preset position Adjust preset Press down preset, enter preset number, press...

  • Page 11: Network Ptz Controller Rotations Description

    Network PTZ Controller rotations description Output Output Output Operate Operate Operate control control control Down Left Output Output Output Operate Operate Operate control control control Right Zoom+ Zoom- Rocker clockwise/rocker counterclockwise: zoom+/zoom one; Long press the middle key: switch between network mode and simulation mode. Rocker middle key short press: confirm;...

  • Page 12: Add Analog Equipment

    Enter the device list, select the newly added device through the rocker left and right, press the middle key of the rocker /[ confirm] for control. Add Analog Equipment Use the keyboard to add analog devices as Add PELCO Device follows: Select : Set One Address...

  • Page 13: Setting/Call Preset

    Keyboard Controller (2) view the saved device from the left Native : 192 .168.1.150 Protocol : PELCO-D right of the rocker, press the rocker Address intermediate key button /[ confirm] > Baudrate : 9600 key to select the camera you need to control.

  • Page 14: Networking

    Networking Home Connection and Login Connect the power cord of the keyboard and connect the network cable. When keyboard is started, the local computer will be displayed on the display screen IP： 192.168.x.xxx, this IP address will be entered into the browser to access the page configuration, the initial user name: admin;...
  • Page 15 (4) Access to the device home page can view the device parameters d etails, can be changed. (5) Click the button to add and modify the device parameters in the LAN . The page is as follows:...

  • Page 16: Web Network Settings

    Enter device number, corresponding IP address, Port number and user name click save. Note: After entering WEB keyboard to add the device successfully and the keyboard for synchronization, after the web page add device successfully click on the keyboard corresponding to the spokes can control the ball. WEB Network settings Network settings can modify the device 's IP acquisition and port parameters, as shown below:...

  • Page 17: Systems Upgrade

    Systems upgrade The upgrade function is used to maintain and update the keyboard function, select the correct upgrade file after entering the upgrade page, click "start ", and the device will restart automatically after the upgrade is completed. PS : upgrade process do not do any operation on the equipment, do not power off, off the network! System Reset When the device is clicked to reset, the controller will clear all data, it is recommended...

  • Page 18: Restart

    Restart When the device is running for a long time and needs to restart maintenance, click restart to achieve the purpose of restart maintenance. Import Configuration Import the device information of the previous keyboard (for example, when the previous keyboard added multiple devices, guide the file type, when adding a new keyboard as import to another device.

  • Page 19: Export Configuration

    Export Configuration Export the relevant information of the current keyboard add multiplexer device, which can be exported to other keyboard devices for use .
  • Page 20 6.8 Version Information Displays hardware and software information for the current keyboard. Note: When adding a device prompt with the onvif protocol fails, check whether the camera turns on the device 's ONVIF protocol.
