OEM Immobilizer - Removing the center console in Audi Q7
1
2
3
4
10
403.VW08 1.39 2020 Audi Q7 (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Step 1: Gently pry and lift rear plate of center console.
Step 2: Remove Torx screws on both ends.
Step 3: Pull out rear trim of center console.
Step 4:
Remove Black 6 pin connector. The immobilizer receiver
is located at the rear of the center console, below rear air vents.
Use the White wire pin 1 (immobilizer receiver side) for OEM Transponder coil.
