Hamlin - 2 Doors Robe
Assembly Instructions
h y g e n a
Dimensions
Width - 80,2cm
Depth - 55,8cm
Height - 192cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
- Please keep for future reference
Customer Helpline: 08456 400 800
152/8062
151/7358
151/2683
Issue 1 - 28/10/13

Advertisement

loading
Need help?

Need help?

Do you have a question about the Hamlin 152/8062 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Hamlin 152/8062

  • Page 1 Hamlin - 2 Doors Robe Assembly Instructions - Please keep for future reference 152/8062 151/7358 h y g e n a 151/2683 Dimensions Width - 80,2cm Depth - 55,8cm Height - 192cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 28/10/13...
  • Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the Do not stand or put weight on We do not components and tools listed on the product, this could cause recommend the pages 2 and 3.
  • Page 3 Components - Panels Please check you have all the panels listed below underside 1 Right side panel (190 x 54cm) 7 Top panel (80.2 x 55.8cm) underside 2 Left side panel (190 x 54cm) 8 Base panel (77 x 54cm) underside 3 Door x 2 (179 x 35cm)
  • Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 Assembly Instructions Step 1 Insert dowels into the indicated parts. Fix hanging rail support in the pre marked holes on right side panel and left side panel using screws , as shown. Step 2 Attention: Fixing L shaped brackets. Unfinished side to face up.
  • Page 6 Assembly Instructions Step 3 Fitting Metal dowels. Screw metal dowels into right side panel left side panel and top panel Insert metal Note: dowels as far as shown. Do not over tighten. Step 4 Fitting hinges. Loosen screw in door hinge and separate the ‘back plate’.
  • Page 7 Assembly Instructions Step 5 Fixing panels and frames. With help, fit base panel , shelf , bottom frame and unfinished bottom frame to left side panel Finished side of base panel face up and finished edges of base panel and shelf to face front.
  • Page 8 Assembly Instructions Step 6 Fixing right side panel. Place right side panel properly ensuring dowels and bottom frames are all fitted into their holes at the same time. nsert ocking nuts into b ase pa and shelf where shown Use a screwdriver to turn locking nuts lockwise to lock...
  • Page 9 Assembly Instructions Step 8 Attention! Attach plastic feet. Make sure nails are fully nailed. Attach p lastic feet the bottom edge of the right and left side panels using nails After attach plastic feet, with help, carefully stand the product upright. Step 9 Insert hanging rail into...
  • Page 10 Assembly Instructions Step 11 Fitting hinges to doors. Insert hinges in the holes on door , as shown. Attach hinges in the the door using screws as shown. Repeat step 11 for the other door. Step 12 Hanging doors. With help, slot door hinges onto ‘hinge plates’.
  • Page 11 Assembly Instructions Step 13 Fixing door knocker. Please note! Edges of painels Attach door knocker must line up at this end. the pre marked holes on door using screws , as shown. Make sure knocker is aligned at top of door before fixing. Repeat step 13 for the other door.
  • Page 12 Assembly Instructions Step continued To move doors left or right: loosen screw shown and move doors to suit. Re-tighten screws. Step 15 Note: Wall plugs not supplied. The correct type of fixing must Fixing to wall. be used for your wall, seek professional advice if in doubt.
  • Page 13: A Guide To - Wall Mounting & Fixings

    A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.

This manual is also suitable for:

Hamlin 151/7358Hamlin 151/2683
