Haversham - 2 Drawer Coffee Table
Dimensions
Width - 105cm
Depth - 55cm
Height - 45cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800
- Please keep for future reference
159/7127
Issue 1 - 18/10/13
Advertisement
Table of Contents
Related Manuals for Argos Haversham
Summary of Contents for Argos Haversham
- Page 1 Haversham - 2 Drawer Coffee Table Assembly Instructions - Please keep for future reference 159/7127 Dimensions Width - 105cm Depth - 55cm Height - 45cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly . Check you have all the . We do not This product contain components and tools listed on Natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below Left front leg ( Right front leg ( 43,2 x 4,5cm 43,2 x 4,5cm Left back leg ( Right back leg ( 43,2 x 4,5cm 43,2 x 4,5cm Top panel 105 x 55cm 06 Back panel (...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Assembly Instructions Step 1 Insert wooden dowels into the indicated parts . Step 2 Insert wooden dowels into the indicated parts . Fully insert Make sure dowels wooden dowels. are exactly the same lenght in both sides. Front view...
- Page 6 Assembly Instructions Step 3 180º Attach runners to the middle wall using screws as shown. Make sure runners are positioned as shown. Step 4 Parts , and are labelled for easier identification. Attach left front leg left back leg to side panel using screws Attach right front leg...
- Page 7 Assembly Instructions Assembly Instructions Step 5 Attach back panel shelf to the side panel and legs using screws Step 6 Attach side panel legs to shelf and back panel using screws...
- Page 8 Assembly Instructions Step 7 Fix middle wall panel to the assembled cabinet using screws Step 8 Fix top panel to the side panels and middle wall using screws...
- Page 9 Assembly Instructions Step 9 With the help of a hammer, fix foot pads as shown. Step 10 Fix large runners side panels using screws...
- Page 10 Assembly Instructions Step 11 a) Attach drawer sides to drawer front using screws b) Slide drawer bottom into slots on drawer sides c) Attach drawer back using screws . Fix handle using screws Step 12 Insert dowels only into the front holes of the runners.
- Page 11 Assembly Instructions Step 13 Place drawers on to runners and slide past dowels fitted to runners. Then, with hammer, tap plastic pins in flush with drawer side, this is a safety catch to stop drawer falling out. Assemble is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800...
