Cheval - Overbed Cupboards
Assembly Instructions -
We recommend that you assemble any
Cheval Robe(s) you may have purchased
BEFORE you assemble these cupboards.
This will enable you to measure the correct
space and height required for the cupboards.
Dimensions
of each
cupboard
Width - 76cm
Depth - 39.5cm
Height - 50cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
147/5634
144/1390
151/3314
146/9918
MADE IN
BRITAIN
Issue 1 - 20/01/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Cheval 147/5634
Summary of Contents for Argos Cheval 147/5634
- Page 1 Cheval - Overbed Cupboards Assembly Instructions - 147/5634 Please keep for future reference 144/1390 151/3314 We recommend that you assemble any 146/9918 Cheval Robe(s) you may have purchased BEFORE you assemble these cupboards. This will enable you to measure the correct space and height required for the cupboards.
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: The combined • Make sure you have enough • We do not weight of the units is space to layout the parts before recommend the approximately 47kgs. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side 3 Top (D2761A) (D2762A) (D2763A) (484 x 372mm) (484 x 372mm) (760 x 393mm) Shelf...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 These instructions will show you how to build 1 overbed cupboard Prepare the left side Screw 2 metal dowels into the left side Note: Tighten the metal dowels up fully against...
- Page 6 Assembly Instructions Step 3 Prepare the base Tap 4 wooden dowels 10mm into the base Note: Wooden dowels must not stick out from the edge by more than Finished 10mm or they may front edge damage other panels. Insert 4 large locking nuts into the base Step 4...
- Page 7 Assembly Instructions Step 6 Fit the left side Push the left side onto the base making sure that the back slots into the groove. Use a screwdriver to tighten the 2 large locking nuts fitted to the base Hold the back place and carefully stand the unit up Step 7...
- Page 8 Assembly Instructions Step 9 IMPORTANT If you are fitting these cupboards between Fit the unit to the wall two robes or, a robe and a wall, please To fix the unit to the wall, measure the space required to fit the place the unit in the cupboards and the height of the robe(s) required position and...
- Page 9 Assembly Instructions Step 10 Joining units together Fittings have been supplied so you are able to join the units together. If required, position any robes that you have assembled up against the cupboards. Using a 5mm drill bit, drill through the two 5mm part-drilled holes in the side panel into the adjoining side panel of...
- Page 10 Assembly Instructions Step 11 Fit the shelf Insert 4 shelf studs the required height. Lower the shelf down onto the shelf studs Step 12 Prepare the 2 doors Push fit 2 hinges into each of the doors Secure each hinge with 2 screws Note: Before securing with the screws, make...
- Page 11 Assembly Instructions Step 13 Fit doors and handles Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinge. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 12 Robe(s) to the wall. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2971...
