Aurora - TV Unit
Assembly Instructions -
Dimensions
Width - 120cm
Depth - 49.5cm
Height - 43.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
158/9544
146/4195
413/9953
MADE IN
BRITAIN
Issue 4 - 26/05/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Aurora 158/9544
Summary of Contents for Argos Aurora 158/9544
- Page 1 Aurora - TV Unit Assembly Instructions - 158/9544 Please keep for future reference 146/4195 413/9953 Dimensions Width - 120cm Depth - 49.5cm MADE IN Height - 43.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 4 - 26/05/15...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 33kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side Divider (D2645A) (D2646A) (D2648A) (420 x 459mm) (420 x 459mm) (385 x 456mm) Horizontal...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the 4 drawer sides Insert a small locking into the hole shown on each of the 2 left drawer sides 2 right drawer sides Note: The arrow on the...
- Page 6 Assembly Instructions Step 4 Prepare the drawer front Screw 4 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels. Step 5 Fit the drawer front Lower the 2 drawer assemblies down onto the back of the drawer front Use a screwdriver to tighten the 4 small...
- Page 7 Assembly Instructions Step 7 Runners must be pushed up against Fit the runners to the the drawer front drawer sides Fit a runner the bottom edge of the left drawer side , as shown, making sure that it is pushed up against the back of the drawer front .
- Page 8 Assembly Instructions Step 8 10mm Prepare the right side Tap a wooden dowel into the right side Note: Wooden dowels must not stick out from the edge by more than 10mm or they may Finished damage other panels. front edge Screw 4 metal dowels into the right side Insert 2 large locking...
- Page 9 Assembly Instructions Step 9 Finished Prepare one of the front edge horizontals Tap a wooden dowel into a horizontal Insert 4 large locking nuts into a horizontal Step 10 Finished Fit the horizontal to front edge the right side Push the horizontal onto the right side f a c s u r...
- Page 10 Assembly Instructions Step 12 Prepare the divider Tap a wooden dowel Finished front edge into the divider Insert 2 large locking nuts into the divider Fit the runner the divider The 1st screw uses the 1st hole in from the front of the runner.
- Page 11 Assembly Instructions Step 13 Prepare the other surface of the divider Fit the runner Finished the divider front edge The 1st screw uses the 1st hole in from the screw screw screw front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 12 Assembly Instructions Step 14 Fit the divider Position the divider against the horizontal and line up their holes. Gently tap the large wooden dowel through the divider and into the horizontal until it ‘’bottoms out’’. Gently tap the 2 double metal dowels through the divider...
- Page 13 Assembly Instructions Step 16 Finished Prepare the other front edge horizontal Tap a wooden dowel into the horizontal Insert 4 large locking nuts into the horizontal Step 17 Fit the horizontal Finished front edge Push the horizontal onto the divider Use a screwdriver to f a c s u r...
- Page 14 Assembly Instructions Step 19 Finished front edge Prepare the left side Tap a wooden dowel into the left side Screw 4 metal dowels into the left side Insert 2 large locking nuts into the left side Fit the runner to the left side The 1st screw uses...
- Page 15 Assembly Instructions Step 20 Fit the 2 rails Push the 2 rails onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to the rails Note: Support this rail until the left side has been fitted in the next step.
- Page 16 Assembly Instructions Step 22 Secure the left side Use a screwdriver to tighten the 2 large locking nuts fitted to the horizontal Step 23 Fit the 2 feet Screw a foot onto each of the 2 rails and on into the bottom edge of the divider using screws Carefully stand the...
- Page 17 Assembly Instructions Step 24 Prepare the top Screw 6 metal dowels into the top Step 25 Fit the top Lower the top down onto the assembly. Use a screwdriver to tighten the 6 large locking nuts fitted to the left side ,right side and divider...
- Page 18 Adjustment If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 20 ALR2940...
