Dining Chair
Assembly Instructions -
Please keep for future reference
1524853/1597048
Dimensions - Chairs(x2)
Width - 42cm
Depth - 44.7cm
Height - 90cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
Issue 1 - 16/04/10
Advertisement
Related Manuals for Argos 1524853
Summary of Contents for Argos 1524853
- Page 1 Dining Chair Assembly Instructions - Please keep for future reference 1524853/1597048 Dimensions - Chairs(x2) Width - 42cm Depth - 44.7cm Height - 90cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product during assembly, recommend the pages 2 and 3.
- Page 3 Components - Panels Please check you have all the panels listed below right left Left & right side apron x 2 (32.6 x 6cm) Front frame x 2 (39.8 x 42.5cm) right left Left & right side rail x 2 Back x 2 (34.8 x 2.2cm) (35.9 x 90cm)
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0845 640 0800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Wood dowels Insert wood dowels into left &right side apron left &right side rail bottom middle rail right left right left...
- Page 6 Assembly Instructions Step 2 Fitting bolts Insert nut into back , screw bolts into nut Insert nut into front frame , screw bolts into nut...
- Page 7 Assembly Instructions Step 4 Step 3 Attaching side apron Attach left side apron to back Insert bolt into y washer Screw nut to bolt using hand . Continued on next page.
- Page 8 Assembly Instructions Step 3 - continued Attach right side apron to the back Repeat step b on page 6. Step 4 Attach side rail Attach left & right side rails to zhe bottom middle rail...
- Page 9 Assembly Instructions Step 5 Attach side rail Attach left & right side rail and bottom middle rail to back Step 6 Attach front frame Attach front frame to the aprons and side rails...
- Page 10 Assembly Instructions Step 7 Insert bolts into fly washers to fix aprons to front frames. Note: Tighten all the bolts. Step 8 Fitting screw Fix side rails and bottom middle rail using screws...
- Page 11 Attach seat to chair frame using screws Repeat with remaining chair. Tighten all the screws for chairs. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Argos Ltd MK9 2NW...
