Constable - Pair of Upholstered Chairs
Assembly Instructions
Dimensions
Width - 46cm
Depth - 60.3cm
Height - 101.3cm
Important
- Please read these instructions fully before starting assembly.
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
IW-17-175R-O12-AVPR/ AVIS-S2X-172-0
- Please keep for future reference
149/2545
156/8565
Issue 1 - 01/07/12
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Constable 149/2545
Summary of Contents for Argos Constable 149/2545
- Page 1 Constable - Pair of Upholstered Chairs Assembly Instructions - Please keep for future reference 149/2545 156/8565 Dimensions Width - 46cm Depth - 60.3cm Height - 101.3cm Important - Please read these instructions fully before starting assembly. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 IW-17-175R-O12-AVPR/ AVIS-S2X-172-0 Issue 1 - 01/07/12...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly. • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the page 2.
- Page 3 If you have damaged or missing components, Components - Panels call the Customer Helpline: 08456 400800 Please check you have all the panels listed below Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 4 Assembly Instructions Step 1 Attaching front legs Place seat pad onto a flat, stable, clean and soft surface. Lift under cloth up and lay back as shown. Position front legs onto seat box Note: Ensure that you put the front legs into the correct place as shown.
- Page 5 Assembly Instructions Step 2 Fixing front legs Insert flat washers lock washers onto threaded bolts then secure into position using hex nuts as shown. Use spanner to turn fitting clockwise to fix. Step 3 Fixing back leg frame Position back leg frame onto seat pad Note:...
- Page 6 Assembly Instructions Step 3 - continued Fix back leg frame to seat pad using 4 bolts as shown. Use allen key to turn fitting clockwise to fix. Step 4 Attaching under cloth Place under cloth back onto frame of seat pad by lining up velcro strips and pushing firmly to fix back in place.
- Page 7 Constable Oak Extension Dining Table Assembly Instructions 176/0325 - Please keep for future reference Dimensions Width - 160/ 200cm Depth - 90cm Height - 75cm Important - Please read these instructions fully before starting assembly. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 IW-17-3205-010-R1 Issue 1 - 12/06/10...
- Page 8 Safety and Care Advice Important - Please read these instructions fully before starting assembly. • Check you have all the • Do not stand or put weight on • We do not the product, this could cause recommend the components and tools listed on page 2.
- Page 9 Components-Table tops & Legs If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the panels listed below. 1 Legs x 4 2 Table top (160/200 x 90cm) (10 x 72.2cm) 3 Extension leaf (90 x 40cm) Components - Fittings Please check you have all the fittings listed below.
- Page 10 Assembly Instructions Step 1 Fitting dowels Insert cross dowels into the holes on top of legs 1 . Ensure the horizontal marking on each cross dowel is facing out as shown. Insert 2 threaded bolts into the two holes on all legs 1 . Tighten threaded bolts into the holes of cross dowels...
- Page 11 Assembly Instructions Step 2 - continued Attaching legs Attach leg 1 onto table top 2 by inserting bolts into the pre-drilled holes of metal corner bracket as shown. Insert flat washer lock washer and hex onto the two threaded bolts leg 1 and in order as shown.
- Page 12 Assembly Instructions Step 3 With help, carefully stand dining table upright. The dining table is heavy. Lift with care. Locate thumbscrews under table ends and turn counterclockwise until clear of locking holes on underside of table top. Extending table Pull both table tops apart as shown.
- Page 13 Assembly Instructions Closing table Locate and turn thumbscrews counterclockwise on both ends of the table until clear of locking holes on underside of table top. Slide both table tops outwards, then lift the extension leaf up. Carefully place the extension leaf onto wood supports under the table as shown.
