Cheval - 2 Door Robe
Assembly Instructions -
Dimensions
Width - 69cm
Depth - 49.5cm
Height - 200cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
146/7965
146/8548
147/4068
152/7324
MADE IN
BRITAIN
Issue 1 - 10/01/14
Advertisement
Related Manuals for Argos Cheval 146/7965
Summary of Contents for Argos Cheval 146/7965
- Page 1 Cheval - 2 Door Robe Assembly Instructions - 146/7965 Please keep for future reference 146/8548 147/4068 152/7324 Dimensions Width - 69cm Depth - 49.5cm MADE IN Height - 200cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 10/01/14...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 44.5kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below 3 Top (D2721A) (690 x 494mm) Left Side Right Side Horizontal (D2720A) (D2719A)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 To fit the rail holder, screw through its top hole and into the shallow mark hole drilled in the Prepare the left side panel.
- Page 6 Assembly Instructions Step 3 Prepare the 2 horizontals Tap 4 wooden dowels into each horizontal Finished Insert 4 large locking front edge nuts into each horizontal Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
- Page 7 Assembly Instructions Step 6 Fit the plinth and rails Push the plinth onto Note: The 2 rails have the right side a finished top edge. Finished top edge Use a screwdriver to Finished tighten the large locking top edge fitted to the plinth Push the 2 rails onto the right side...
- Page 8 Assembly Instructions Step 8 Fit the top and the plastic nails Push the top onto the assembly and secure it to the sides using 4 screws Tap 2 plastic nails into the bottom edge of each of the sides as shown. Finished front edge Step 9...
- Page 9 Assembly Instructions Step 10 Fit the hanging rail Push the hanging rail into the rail holders fitted to the side panels. Step 11 Prepare the 2 doors Push fit 3 hinges into each of the doors Secure each hinge with 2 screws Note: Before securing with the screws, make...
- Page 10 Assembly Instructions Step 12 Fit doors and handles Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 11 Assembly Instructions Step 13 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 12 Lift with care. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2962...
