9. Restore the lifting lugs to their original positions.
Ground stud
Silicone sealant
FELCOM 250: How to install the antenna unit
Carefully unpack the radome and check for damage. Run the antenna cable before installation of
the antenna unit.
Antenna unit installation materials
Item
Silicone sealant
Rubber mat
Radiation warning sticker (S) 2
Radiation warning sticker (L)
Hex nut
Spring washer
Flat washer
Ground wire
Silicone sealant
Seal washer
Rubber mat
Quantity
1
50 g
1
This mat may be pre-attached to the antenna unit
depending on the date of production.
1
12
M6
6
M6
6
M6
1
200 mm, W/6 mm crimp-on lug for both ends
8
1. HOW TO INSTALL THE UNIT
Nut
Spring washer
Flat washer
Bolt
Silicone sealant
Remarks
