FELCOM 500: How to install the antenna unit

Carefully unpack the radome and check for damage.

Antenna unit installation materials

Item

Silicone sealant

Rubber mat

Radiation warning sticker

Hex bolt

Hex nut

Spring washer

Flat washer

Seal washer

Procedure

1. Loosen four lifting lugs and turn them to outside at the bottom of the radome as shown in the

figure on the next page. Then fasten four screws for lifting lugs firmly.

2. Run lifting rope with shackles through lifting lugs.

3. Cover the part of the radome which contacts the lifting rope with protective material (rubber

mat, etc.), to prevent damage to the radome when hoisting it to the mounting location.

4. Lift the antenna unit to the mounting location.

Quantity

Remarks

50 g

M10x60

M10

1. HOW TO INSTALL THE UNIT
