LED
1000BASE-X fiber port
LED
10GBASE-R fiber port
LED
Interface module LED
Power module LED
9

Appendix C Cables

Console cable

RJ-45 to DB9 console cable

An RJ-45 to DB9 console cable is used to connect the console port on the firewall to the serial port on
a configuration terminal (a PC for example):
•
Connect the DB9 female connector of the cable to the 8-core serial port on the configuration
terminal.
•
Connect the RJ-45 connector of the cable to the console port on the firewall.
Figure9-1 RJ-45 to DB9 console cable
A
Pos.9
A
Pos.1
Table9-1 RJ-45 to DB9 console cable pinouts
RJ-45
1
2
3
4
Mark Status
Off
1000BASE- Steady green
X
Flashing green
Off
10GBASE- Steady green
R
Flashing green
Off
SLOT1,
SLOT2
Steady green
Off
PWR0,
PWR1
Steady green
W
Signal
RTS
DTR
TXD
CD
9-58
Description
No link is present.
A 1000 Mbps link is present.
The port is receiving and sending data at
1000 Mbps.
No link is present.
A 10 Gbps link is present.
The port is receiving and sending data at 10
Gbps.
No interface module is present or the
interface module has failed.
The interface module is operating correctly.
No power module is present or the power
module has failed.
The power module is operating correctly.
B
B
Pos.1 Pos.8
Direction
←
←
←
→
DB-9
7
4
3
1
