Table7-1 displays the slots available for interface module installation.
Table7-1 Interface module and device slot compatibility
Firewall model
F1005/F1010
F1020
F1030/F1040/F1050/F1060/

F1070/F1080

F1090

NSQM1GT4PFC

The NSQM1GT4PFC interface module provides four 10/100/1000BASE-T Ethernet copper ports.
•
When the firewall is operating correctly, the four ports operate as common data ports.
•
When the firewall is powered off, the four ports are divided into two bypass port pairs with ports
0 and 1 in one pair and ports 2 and 3 in another pair. The two ports in a pair can act as the uplink
and downlink interfaces for a Layer 2 link and form a bypass link. This enables traffic to be
transmitted through the firewall even if the firewall is powered off and ensures service
continuity.
Figure7-11 Front panel of the NSQM1GT4PFC interface module
(1) 10/100/1000BASE-T copper ports
(3) Ejector lever

NSQM1GP4FBA

The NSQM1GP4FBA interface module provides four 1000BASE-X fiber ports.
Slot number
N/A
Slot 1
Slots 1 and 2
Slots 1 to 3
Slots 2 to 4
1
3
(2) Captive screw
7-47
Slot specification
N/A
Low speed
Low speed
High speed
Low speed
2
Available interface
modules
Not supported
•
NSQM1GT4PFC
•
NSQM1GP4FBA
•
NSQM1GT4PFC
•
NSQM1GP4FBA
NS-NIM-TG6A
•
NSQM1GT4PFC
•
NSQM1GP4FBA
