Appendix B LEDs

The F10X0 firewalls use similar LEDs. This section uses the LEDs on the F1080 firewall as an
example.
Figure8-1 LEDs
(1) System status LED
(3) 10/100/1000BASE-T copper port LED
(5) 10GBASE-R fiber port LED
(7) Power module LED
Table8-2 LED description
LED
System status LED
Drive status LED
10/100/1000BASE-T
copper port LED
Central
Connector
wavelength
1310 nm LC
1550 nm LC
1 2
7 6
Mark Status
Off
SYS Slow flashing green
Fast flashing green
Off
HD0, HD1 Fast flashing green
Steady green
Off
10/100/100
Steady green
0BASE-T
Flashing green
8-57
Fiber
fiber
50/125 µm multi-mode
optical fiber
9/125 µm single-mode
optical fiber
9/125 µm single-mode
optical fiber
3 4
(2) Drive status LED
(4) 1000BASE-X fiber port LED
(6) Interface module LED
Description
The firewall is not powered on or has failed.
The firewall is operating correctly.
The firewall is loading software.
The firewall is not powered on or has failed.
Data is being read from or written to the
drive.
The drive is present and operating correctly.
No link is present.
A link is present.
The port is receiving and sending data.
Max
transmission
distance
220 m (721.78 ft)
100 m (328.08 ft)
10 km (6.21 miles)
40 km (24.86 miles)
5
