Dimensions and weights

The weight of the firewall includes the chassis and its removable components.

Chassis

Table7-4 Chassis dimensions and weights
Firewall model
F1005/F1010
F1020
F1030/F1050/F1060
F1070/F1080
F1090

Interface modules

Table7-5 Interface module dimensions and weights
Interface module model
NSQM1GT4PFC
NSQM1GP4FBA
NS-NIM-TG6A

Drives

Table7-6 Drive dimensions and weights
Drive model
NS-SSD-480G-SATA-SFF
NS-HDD-500G-SATA-SFF
NS-HDD-1T-SATA-SFF

Storage media

Table7-7 Storage media specifications of the device
Firewall model
F1005/F1010
F1020
F1030/F1050
F1060/F1070
Dimensions (H × W × D), excluding rubber
feet and mounting brackets
44 × 440 × 230 mm (1.73 × 17.32 × 9.06 in)
44.2 × 440 × 435 mm (1.74 × 17.32 × 17.13 in)
44.2 × 440 × 435 mm (1.74 × 17.32 × 17.13 in)
44.2 × 440 × 435 mm (1.74 × 17.32 × 17.13 in)
44 × 440 × 435 mm (1.73 × 17.32 × 17.13 in)
Dimensions (H × W × D)
19 × 150 × 172.9 mm (0.75 × 5.91 × 6.81 in)
19 × 150 × 172.9 mm (0.75 × 5.91 × 6.81 in)
19 × 150 × 172.9 mm (0.75 × 5.91 × 6.81 in)
Dimensions (H × W × D)
19 × 75.7 × 118.4 mm (0.75 × 2.98 × 4.66 in)
19 × 75.7 × 118.4 mm (0.75 × 2.98 × 4.66 in)
19 × 75.7 × 118.4 mm (0.75 × 2.98 × 4.66 in)
Memory
2GB DDR3
2GB DDR3
4GB DDR3
8GB DDR3
7-52
Weight
3 kg (6.61 lb)
6.75 kg (14.88 lb)
7.3 kg (16.09 lb)
8.5 kg (18.74 lb)
10 kg (22.05 lb)
Weight
0.45 kg (0.99 lb)
0.42 kg (0.93 lb)
0.4 kg (0.88 lb)
Weight
0.069 kg (0.15 lb)
0.12 kg (0.26 lb)
0.14 kg (0.31 lb)
