Pre-installation and application warnings

Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
Important! The following settings must be made for the 2016 - 2019 Chevrolet Malibu Hybrid (Smart Key). The Remote
Š
Starters tachometer setting set Engine Checking Mode to OFF and Cranking Time (in seconds) to 4.0 seconds or similar.
Important! Wait 10 seconds after remote start shutdown before remote starting the vehicle again.
Š
Key2GO is mandatory to control the immobilizer override in this firmware.
Š
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
Š
connector.Refer to the "Vehicle connections" following the installation diagram.
General notes: This section highlights important information for this specific firmware.
Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.
[1]
Hook up brake for automatic transmission vehicles or clutch for manual transmission vehicles.
[2]
5
403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
Keys required for 1 Keys required for
programming operation
0
