Wiring Diagram - Directed DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
D2D Port
(-) Parking Lights Output
(+) 12V Input
(-) Ground (-) Ground
(AC) Tach Intput
(+) Ignition Input
6 403.GM9 2.38 2016 Buick Verano (Smart Key)
© 2021-01-25 Directed. All rights reserved.
BCM
(white conn. under
driver-side dash
or in center console
passenger side)
1 2 3 4
5 6 7
8 9
10 11 12 1314
15 16 17 18 19 20
21 22 23 24 25 26
(-) Parking Lights:
Pin 22
(+) 12V: Pin 4
BCM (blue conn. under
driver-side dash or in center
console passenger side)
1 2 3 4
(MUX)
Brake: Pin 7
5 6 7 8
9
11 12 13 14 15
10
Single Wire
16 17 18 19 20 21
CAN: Pin 22
22 23 24 25 26 27
HS CAN High:
HS CAN Low:
Pin 24
Pin 23
Clutch Switch
(black 3-pin
A B
connector)
BCM
(green conn.
under driver-side
dash or in center
console passenger side)
1 2 3 4 5 6 7
8
10 11 12 1314
15 17 18 19 20
21 23 24 25
Immo. Data:
Green/Violet or
Cut
Lt. Blue, pin 2
Single Wire CAN: Lt. Green: 1
HS CAN High: Tan/Black: 3
Immo Data Interr. (conn. side): Yellow: 8
Immo. Data Interr. (veh. side): Orange/Yellow: 9
(MUX) Clutch Output: Yellow/Red: 11
Clutch: Brown/Red: 12
180 Ohms Resistor
(AC) Tach Output: Violet/White: 5
(+) Ignition Status Output: Gray/Black: 7
(MUX) Brake Activation Output: Violet/Brown: 9
Immo. Data (conn. side): Yellow/Black: 10
(MUX) Clutch: pin B
C
HS CAN Low: Tan: 4
).
XKD2D65
