Service Procedures for the Magnetics
9. Push-to-disconnect the 90° gas inlet fitting
quick-disconnect receptacle.
10. Remove the following components from the torch
quick-disconnect receptacle:
Retention nut

Ring terminal

11. Remove the output inductor.

Install the output inductor

1. Put the output inductor wires through the open space
2. Put the tabs on the rear of the output inductor into the slots
power supply.
3. Attach the output inductor to the plasma power supply with the
2 supplied mounting screws. Tighten screws to 2.3 N∙m
(20 lbf∙in).
4. Pull the electrode wire
128
4
5
through the protective sheath
3
810440
from the torch
3
3
in the bottom of the center panel.
1
on the bottom of the plasma
2
1
2
.
4
4
Service Parts and Procedures
4 5
3
Powermax65/85 SYNC
