Replace the heatsink components

For kit contents, refer to
Refer to the following procedures for instructions on how to replace each heatsink component:
Replace the output diode bridge

Replace the input diode bridge

Replace the pilot arc IGBT

Replace the inverter IGBT and the thermal sensor

Replace the PFC IGBT

Replace the snubber resistors and the damper resistor

It is very important to correctly clean the heatsink and to apply thermal grease to the new
component before you install it.
Refer to How to clean the heatsink and apply thermal grease to the heatsink components
