Quick Start Guide — DVI DA2 and DA4
To install, cable, and power on the DVI DA2 and DVI DA4:
Step 1 Installation
Install the DVI DA2 or DVI DA4 on a desk, mount it under a desk, or
mount it in a rack.
Step 2 DVI Cable Connections
Connect a DVI cable from the Input connector to the video
source device.
Connect a DVI cable from the Local Output connector to the
desired local output device.
Connect a DVI cable(s) from the Output connector(s) to the desired
display device(s).
