Summary of Contents for Kramer SL-12
- Page 1 K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODEL: SL-12 Master Room Controller P/N: 2900-000552 Rev 7...
-
Page 3: Table Of Contents
Connecting the K-NET Port Operating the SL-12 Technical Specifications Figures Figure 1: SL-12 Master Room Controller Figure 2: Connecting the SL-12 Master Room Controller Figure 3: SL-12 IR Inputs Figure 4: RS-232 Connection Figure 5: RS-485 Connection Figure 6: K-NET Pinout Connection... -
Page 4: Introduction
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products; GROUP 12: Digital Signage; GROUP 13: Audio; and GROUP 14: Collaboration. Congratulations on purchasing your Kramer SL-12 Master Room Controller, which is ideal for the following typical applications: ... -
Page 5: Getting Started
Avoid interference from neighboring electrical appliances that may adversely influence signal quality Position your Kramer SL-12 away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 6: Safety Instructions
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country... -
Page 7: Overview
Overview The SL-12 is a highly versatile controller that acts as an all-in-one control processor for control of AV equipment—especially projectors and associated equipment—in any room (such as classrooms, boardrooms, or auditoriums). It streamlines operations and simplifies control by integrating audio, video, and computer-video sources into a centralized system. -
Page 8: Defining The Sl-12 Master Room Controller
Defining the SL-12 Master Room Controller This section defines the SL-12. Figure 1: SL-12 Master Room Controller Feature Function ETHERNET RJ-45 Connects to the PC or other serial controller through Connector computer networking LAN to control several AV products over Ethernet... - Page 9 PIN GND is for the Ground connection; PIN B (-) and PIN A (+) are for RS-485, and PIN +12V is for powering other units Note that the SL-12 cannot receive power via the K-NET connector, but can power other units (but not another SL-12)
-
Page 10: Connecting The
Connecting the SL-12 Always switch off the power to each device before connecting it to your SL-12. After connecting your SL-12, connect its power and then switch on the power to each device. To connect the SL-12 as illustrated in the example in Figure 1. -
Page 11: Figure 2: Connecting The Sl-12 Master Room Controller
Connect RS-232 port 1 to the projector Connect RS-232 port 3 to the plasma display 6. Connect the RS-485 to several Kramer matrices, for example (not shown in Figure 7. Connect the Ethernet port to a network. 8. Connect the K-NET port to any RC device with K-NET. -
Page 12: Using The Rc-4 Ir Transmitter
IR receiver on the front panel, and/or via the optional external IR receiver (C- A35M/IRR) that exists in several cable lengths. IR Input Functionality The SL-12 front panel includes one built-in receiver and two IR inputs on 3.5mm jacks (shown in Figure 3) for control via the RC-4. -
Page 13: Connecting The Rs-232 Interface
IR receiver. Connecting the RS-232 Interface To connect an AV device to the SL-12 using the RS-232 port, connect the RS-232 9-pin D-sub port on your device to the RS-232 terminal block on the rear panel of... -
Page 14: Connecting The Rs-485 Interface
Figure 4: RS-232 Connection Connecting the RS-485 Interface To connect an AV device to the SL-12 using the RS-485 port, connect the RS-485 port on your device to the RS-485 terminal block on the rear panel of the SL-12 as shown in Figure... -
Page 15: Connecting The K-Net Port
Operating the SL-12 You can operate your SL-12 using: An RC family remote controller: To operate your device using an RC remote controller, see the Kramer K-Config Guide The optional RC-4 infrared remote control transmitter: The RC-4 is configured via the Kramer K-Config software... -
Page 16: Technical Specifications
Power supply RK-13 19” rack mount, RC-4 remote controller, IR emitter OPTIONS: cables (P/N: C-A35/IRE-10; two IR Emitter Extension Cables are also available: a 15 meter cable and a 20 meter cable), IR sensor cable (P/N: 95-0104050) SL-12 - Technical Specifications... - Page 17 This limited warranty gives you specific legal rights, and you may have other rights which vary from country to country or state to state. This limited warranty is void if (i) the label bearing the serial number of this product has been removed or defaced, (ii) the product is not distributed by Kramer Electronics or (iii) this product is not purchased from an authorized Kramer Electronics reseller.
- Page 18 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. SAFETY WARNING Disconnect the unit from the power supply before opening and servicing P/N:...
