PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 2 C1, C2
2 6 C3, C4, C102-C105
3 4 C5-C8
4 8 C9-C16
5 1 C17
6 2 C18, C19
7 2 C101, C106
8 5 E1-E5
9 4 JP1-JP4
10 1 JP101
11 7 J1-J7
12 8 L1-L4, L11-L14
13 4 L5-L8
14 2 L9, L10
15 4 L15-L18
16 2 R101, R107
17 5 R102-R106
18 3 R108-R110
19 2 T1, T2
20 1 U1
21 1 U101
22 1 U102
23 2 U103,U104
24 1
PART DESCRIPTION
CAP ., 4.3pF, C0G, 50V, ±0.1pF, 0402
CAP ., 2.2pF, C0G, 50V, ±0.1pF, 0402
CAP ., 1000pF, X7R, 50V, 10%, 0201
CAP ., 10nF, X7R, 50V, 10%, 0402
CAP ., 0.3pF, C0G, 25V, ±0.05pF, 0201
CAP ., 1µF, X5R, 50V, 10%, 0603
CAP ., 0.1µF, X7R, 50V, 10%, 0402
TEST POINT, TURRET, .064 MTG. HOLE
JMP , 3PIN 1 ROW .079CC
HEADER, 2 × 7PIN, 0.079CC
CON., SMA, 50Ω, EDGE-LANCH
IND., 680nH, 5%, 0603
IND., 47nH, 2%, 0402
DNI
IND., 33nH, 2%, 0402
RES., 200k, 1%, 0402
RES., 1k, 1%, 0402
DNI
DNI
300MHz to 6GHz Dual Programmable Gain
Downconverting Mixer
DNI
Dual Supply Translating Transciever, 3-state
Dual Buffer with 3-state output
CABLE ASSY., 8" STRIP
DEMO MANUAL DC2460A
MANUFACTURER/PART NUMBER
Murata, GJM1555C1H4R3BB01
Murata, GJM1555C1H2R2BB01
Murata, GRM033R71H102KA12
Murata, GRM155R71H103KA88
Murata, GRM0335C1HR30WA01
Murata, GRM188R61H105KAAL
Murata, GRM155R71H104KE14
MILL-MAX,2308-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
MOLEX, 87831-1420
EF JOHNSON, 142-0701-851
COILCRAFT, 0603AF-681XJE
COILCRAFT, 0402HP-47NXGL
DNI
COILCRAFT, 0402HP-33NXGL
Vishay, CRCW0402200KFKED
Vishay, CRCW04021K00FKED
DNI
DNI
Linear Tech., LTC5566IUH#PBF
DNI
NXP , 74LVC1T45GW
FAIRCHILD, NC7WZ17P6X
LINEAR RIBBON CABLE CA-2440
