- Page 1 SUNE TECH Installation Manual SUNE10 PLUS-LC200/20RX Manual Date 2020, 02, 07 2020, 01, 15 Main 2020, 01, 15 Firmware Date 2020, 01, 15 Tw8823...
- Page 2 SUNE TECH LC200 LC200 Universal AV-Cable Key-Pad Speaker GLONASS GPS WIFI/BT Antenna x 2 A10-LC200 Universal AV-Cable WiFi/BT Antenna x 2...
- Page 3 SUNE TECH New GVIF Cable Old GVIF Cable option option LC200 Power 1on1 Power RX300 option option...
- Page 4 SUNE TECH AV IN/OUT Speaker P Speaker N Audio Out R Ground POWER / CAN AV IN Audio Out L Ground ACC IN Ground 1, 2 DVB-T Video Mic P Mic N Aux Detect ADC 2 3, 4 DVB-T Audio R ADC 1 5, 6 DVB-T Audio L...
- Page 5 SUNE TECH Switch Model Inch Used HDMI Input LC200 2019 ~ Used Rear Camera Input RX300 2019 ~ Used Front Camera Input RX300 2019 ~ Used DVB-T (CVBS) Input LC200 2016 ~ 2018 Used DVD (CVBS) Input reserved List of Car Model SW10 Model Inch...
-
Page 6: Hdmi Device
SUNE TECH HDMI DEVICE REAR / FRONT DVB-T From HEADUNIT From HEADUNIT Please connect both ES CAN Connector to each other. Please connect RX CAN Connector to connector of extension cable. RX CAN ES CAN... - Page 7 SUNE TECH From HEADUNIT From HEADUNIT...
- Page 8 SUNE TECH GROUND OEM Rear Camera is working automatically. REAR 12V OUT So if install some device as Rear Camera. It should be wire cut. In this case, cut the wire of the power connector of the monitor. And please connect wire which cut to NC ( Normal Close ) of Relay. When the screen is switched to the rear view screen, 12V is supplied to the Relay wire colors may be different for each vehicle.
- Page 9 Steer Remote How to press Description of operation Return back to OEM Screen form Press button for short time Interface Screen HOME Screen is switched in that order Press button for 1 second switches are activated. INFO Return back to OEM Screen form AUDIO Press button for short time Interface Screen...
- Page 10 Steer How to press Description of operation Remote 1, HandsFree Return back to OEM Screen form Press button for short time calling Interface Screen Screen is switched in that order switches are activated. 2, Seek In DVB-T mode, Press button for short time Up/Down Change channel to up In DVB-T mode,...
- Page 11 SUNE TECHNOLOGY CO.,LTD No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN TEL:+88662292246 FAX:+88662288104 Http://www.sune-tech.com Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_han99 Copyright ⓒ 2019 by SUNE TECHNOLOGY...
