• The Options for Size, Grooving Depth and Polishing can be simultaneously
selected in Retouch Mode. Simply set up e required value of adjustment for
Size and Grooving Depth.
• In case the operator made an error to activate Rimless Mode instead of Semi-
Rimless, the operator can select the Grooving Depth for Semi-Rimless Edging.
However, the Grooving Position cannot be selected.
• In case the operator made an error not to activate Polishing, the operator can
execute Polishing by way of pressing the Polishing button one more time. The
Polishing Button activates alternately by pressing it.
• The recommended Retouch Size will be 1/3 of the length shown as (a).
• TAB button is not available in Retouch Mode. Finish the Retouch Mode with
EXIT Button.
• Even though the Retouch Mode is completed with EXIT button, the operator re-
activates the Retouch Mode unless he activates the Edging Mode.
• Be sure not to remove the Lens Adapter to activate the Retouch Job.
• No Option Menu other than Right/Left Selection is available in Retouch Mode.
Operation Tips
!
NOTE
(a)
