Flight Model F3A Magpie 59" Assembly Manual
  1. Manuals
  2. Brands
  3. Flight Model Manuals
  4. Toy
  5. F3A Magpie 59"
  6. Assembly manual

Flight Model F3A Magpie 59" Assembly Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Wing Span:1500mm/59in; Flying Weight:2300-2500g;
Wing Area:39.9sq.dm;
Length:1537mm/60.5in;
Prop:16*8;
CAUTION : this plane is not a toy and should be kept away
children under 16 years of age! Before use , please carefully read
this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
performance to full extent .
●Assemble this kit only in places out of children's reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
Radio:6Channel4Servos;
Esc: 60-80A
Motor: Scorpion 4020-16

Advertisement

loading
Need help?

Need help?

Do you have a question about the F3A Magpie 59" and is the answer not in the manual?

Questions and answers

Related Manuals for Flight Model F3A Magpie 59"

Summary of Contents for Flight Model F3A Magpie 59"

  • Page 1 Wing Span:1500mm/59in; Flying Weight:2300-2500g; Wing Area:39.9sq.dm; Radio:6Channel4Servos; Length:1537mm/60.5in; Esc: 60-80A Prop:16*8; Motor: Scorpion 4020-16 CAUTION : this plane is not a toy and should be kept away children under 16 years of age! Before use , please carefully read this manual. ●First-time builders should seek advice from people having building experience in order to assemble the model correctly and to produce its performance to full extent .

  • Page 2: Main Wings

    Main Wings Connect the aileron and the main wing by hinges.Be sure to apply instant type glue to both sides of each hinges. Install the aileron horns in place with AB glue Align the holes in the horns Cut the servo holes on the bottom of the main wings...
  • Page 3 Cut the film covering as shown Insert the fiberglass control horn. Install the ball links as shown...
  • Page 4 Put the servo into the hole Screw the servo with self-tapping screw Use AB glue to glue the fiberglass control horn Install the ball links onto the servo arm and...
  • Page 5 the control horn with stainless push rod supplied. Connect the main wings and the fuselage with Carbon fiber tube. Use screw to lock it Main Landing Gear and Tail Wheel Unit Gather the parts for the main landing gear.
  • Page 6 Use screw to connect the landing gear, wheel pant, nut and wheel in turn, and finally use a lock nut to lock them. Install the wheel cover,and fix it up to landing gear with screw. Cut hole at the Original design hole of the fuselage...
  • Page 7 Fix up the landing gear on the fuselage bottom with screws. Stabilizer And Rudder Gather the parts for the Elevator and rudder servo As shown...
  • Page 8 Gather the parts for the Stabilizer. Put the elevator push rod in the hole Connect the stabilizer and the fuselage with AB glue...
  • Page 9 Fix up the stabilizer and elevator with hinges and AB glue. Connect the stabilizer and push rod with AB glue Finished Photo Cut out the hinges film as shown...
  • Page 10 Insert the fiberglass control horn into the elevator Use AB glue to glue it. Install the elevator servo as shown...
  • Page 11 Finished photo Push rod diagram The steel wire bent into the shape of the seven.
  • Page 12 Finished photo Rudder Gather the parts for the Rudder Fix up the rudder with hinges and AB glue.
  • Page 13 Drill a hole on the bottom rudder. Put the tail wheel parts in the hole use screw to lock the tail wheel onto the fuselage tail. Finished photo...
  • Page 14 Cut the servo hole on the fuselage left side Install the servo and fix it with screws.
  • Page 15 Finished photo The steel wire bent into the shape of the seven. Connect the servo arm and the control horn with push rod Insert the cover in the fuselage and fix it with screws.
  • Page 16 Install the motor.as shown Drill a hole on the cowl.as shown Install the cowl and fix it with screws.
  • Page 17 Finished photo CG POSITION & CONTROL THROWS...
