CAUTION: This plane is not a toy!
Please read this manual in its entirety before
attenpting to assemble the model
Wing span: 1126mm
Wing area: 44.36sq.dm
Flying weight:1000-1200g
Length: 1145mm
Engine:2cycle 25-31
Radio:4channel 5servos
Outer runner brushless motor
Glow & electric RC model
Advertisement
Related Manuals for Flight Model F055 Butterfly-3D
Summary of Contents for Flight Model F055 Butterfly-3D
- Page 1 CAUTION: This plane is not a toy! Please read this manual in its entirety before attenpting to assemble the model Wing span: 1126mm Wing area: 44.36sq.dm Flying weight:1000-1200g Length: 1145mm Engine:2cycle 25-31 Radio:4channel 5servos Outer runner brushless motor Glow & electric RC model...
- Page 2 Aileron glue the aileron Fuselage cut the slot from the tail of the fuselage for the stablilizer and the servos. install the servo in the fuselage, and the horn on the elevator...
- Page 3 use the elevator pushrod to contact this two parts together TP SCREWS install the tail wheel as shown, and connect the rudder to the fuselage by glue the tail wheel to the rudder screws install the servo to the vertical...
-
Page 4: Landing Gear
Landing Gear... - Page 5 Install the motor Airscrew:12*8 / 11*7 Brushless speed controller:20-30A Battery:11.1-14.4V 2000mAh Li-poly Recommend model weight:1200-1600g Install the engine Install the throttle servo in the fuselage...
-
Page 6: Install The Fuel Tank
Install the fuel tank Main Wing cut the slot in the back of the wing. install the servos into the slot pull the linkages out from the hole in the middle of the wing install the horn on the Aileron... - Page 7 insert the wing into the fuselage with the bolt inserted into the hole in the fuselage use the steel stick, one side link the servo, another to the horn Canopy screw the canopy with the wing onto the fuselage...
- Page 8 Finished Picture...
- Page 9 CG & Control throws...
