Page 1
For Intermediate & Advanced Fliers. SAFETY PRECAUTIONS This radio control model is not a toy! Fist-time builders should seek advice from people having building Experience in order to assemble the model correctly and to produce Its performance to full extent. Assemble this kit only in places out of children’s reach! Take enough safety precautions prior to operating this model.
Page 2
Elevator Cut film and cut four slot as the show. Glue the hinges with Epoxy. Drill a 3mm hole for Elevator control horn. Install Elevator horn as show.
Page 3
Trim out the film as show. Install Elevator as show. Install Elevator servo as show.
Page 4
Install Elevator servo hatch as show. Install Elevator servo , horn and linkage as show. Install STB. Join and anti roll pin as show. Then glue them all in piece with Epoxy.
Page 5
Install Stb. In other side of Fus. as show. The drill a 2.3mm hole , then use a 3X15mm TP. Screw to lockup the Stb. Rudder Cut film and cut three slot as the show. Glue the three copper hinges with Epoxy. Parts need:3 copper hinges.
Page 6
Cut a slot Rudder control wire. as the show Install Rudder control wire. Drill a 3.5 hole at the root of Fin.
Page 7
Install the rudder as the show. Place the two hard wood stick and glue it inside tail of Fus. Install the tail landing gear as show.
Page 8
Install the control put put as what kind of that you use. We are use Robart Retacts 160 or 160wc. Aileron: Cut film and cut three slot as the show. Glue the three copper hinges with Epoxy. Parts need:3 copper hinges. Supply from separately.
Page 9
Install the Aileron control horn as show. Trim off the film at the servo bay as show. Install Aileron servo , horn and linkage as show.
Page 10
Flap: Cut film and cut three slot as the show. Glue the three copper hinges with Epoxy. Parts need:3 copper hinges. Supply from separately. Notice: the Hinges should be install at the lower part of LE. Of Flap. Drill a 3mm hole for Flap control horn. Install Flap servo , horn and linkage as show.
Page 11
Install the wing panel wing join. Drill a 6mm hole from root first. Then place the 6mm pin from left to right side of wing as show. Use lock pin and O ring wish to hold the wing panel together as show.
Page 12
Place the wing panel on fus. Bottem. Then drill two 6mm hole from fus. As show. Install two wing pin at fount of wing . Let at least 25mm out of the hole. Then glue it together with Epoxy. Place wing panel on the fus. Bottem again with wing pin.
Page 13
Follow the 6mm wing bolt hole to drill two 8mm hole for blind nuts Install blind nuts and glue it with epoxy. Install the retact gear as show. We recommend “Robart Retacts” #154. Install the wheel cover as show.
Page 14
Install the wheel cover as show. Notice the wheel should be use 5in wheel. Option part: Drill two small hole on to the tank mount as show. Place the tank mount on the tank and follow the small hole you just drill and drill two small hole again to the tank.
Page 15
Use two TP. Screw to lockup the tank and tank mount as show. Drill two 10mm hole at the wing root first. Then place the tank under the wing panel and drill two 3mm hole for tank mount bolt. Install two 3mm blind nuts inside the tank mount and glue it with Epoxy.
Page 16
Install the tank as the show. Notice: you need install the wing panel before you install the tank. Drill the wing bolt hole as your motor mount . Notice, there have 2 degree right thrust and 2 degree down thrust. We recommend use 65cc-80cc Gas motor.
Page 17
Diver hub should be have 10-15mm out from cowl end. Place the Exhaust pipe on to the hard wood block then use 3X15 TP. Screw to fix it as show. Glue six exhaust pipe with wood block as show. And also glue four cowl mount wood block as show.
Page 18
Notice. When you install the exhaust pipe you need to check and follow the position of cowl, because the exhaust pipe position was a bit differ in differ side of the cowl. Drill four 2mm hole at differ side of the cowl and use 3X15mm TP.
Page 19
Glue the cockpit to the interior as show. Install the cockpit panel inside the fus. as show. Then use thick CA. to glue it together. Follow the mark on canopy use heat gun to bend the edge of canopy inside 90 degree as show.
Page 20
Install the Antenna and glue it together with Epoxy as show. Cut a open at rear canopy as show to allow the Antenna out of the canopy. Install the rear canopy as show. Fix it with 3 pcs. 2.5 X 10 TP. Screw.
Page 21
Install Font canopy and fix it with four 2.5 X 10 TP. Screw as show. Install Mid. Canopy as the show. If you going fly the airplane. You need fix the Mid. Canopy with four 2.5 X 10 TP. Screw.
SPECIFICATION A048 ZERO A6M5B CODE ITEM 2319.4mm/91.3" 65-80CC GAS WING SPAN ENGINES CLASS 93.4 d㎡ WING AERA RTF. WEIGHT 13-15.5 Kg 1773.2mm FUS. LENGTH 2101mm TOTAL LENGTH CENTER OF GRAVITY From LE. 26-28% 2° 2.96d㎡ RUDDER AREA WING INCIDENCE 5.7°...
