Wing span: 62.2in/1580mm
Length: 50.3in/1280mm
Engine:2cycle 60,4cycle 90
CAUTION: This plane is not a toy!
Please read this manual in its entirety before attempting to
assemble the model.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
performance to full extent .
●Assemble this kit only in places out of children's reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
Wing area: 41sq.dm
Flying weight:3000g
Radio:4channels 6servos
Advertisement
Related Manuals for Flight Model F090 CAP232-60
Summary of Contents for Flight Model F090 CAP232-60
- Page 1 Wing span: 62.2in/1580mm Wing area: 41sq.dm Length: 50.3in/1280mm Flying weight:3000g Engine:2cycle 60,4cycle 90 Radio:4channels 6servos CAUTION: This plane is not a toy! Please read this manual in its entirety before attempting to assemble the model. ●First-time builders should seek advice from people having building experience in order to assemble the model correctly and to produce its performance to full extent .
- Page 2 Main Wing Put the servo into the cutout, and pull the Glue the aileron. liner out from the hole. Cut the servo holes on the back of the main wings. Screw the hors onto the ailerons. Link the Connect the servo and servo liner. servos with L locks as shown.
-
Page 3: Landing Gear
Stabilizer Insert wings to the fuselage as shown. Line the position, remove the cover, and glow the stabilizer to the fuselage. Landing gear Install the wheels as shown, and fasten them to the landing gear. Glow the aileron of the stabilizer. Rudder Screw the landing gear to the fuselage. - Page 4 Fuselage Cut the hole for the servo. Tailwheel Screw the tailwheel on the fuselage. Install the horn and the pushrod as shown. Connect the servo and the horn as shown.
- Page 5 Install rudder and elevator servo . Engine Make sign of the hole, and drill holes for the engine mount. Fuel tank Install the fuel tank as shown.
- Page 6 Screw the engine mount, and install the Connect the linkage servo and the engine engine as shown. with a pushrod as shown. The length from the firewall to the top of Screw the cowling with 4 bolts the engine should be 130mm. Factory mounted 4 nuts for canopy installation.
- Page 7 Motor Install motor as shown. CG & Control Surface Movement...
- Page 8 Adjustment Another scheme for choice. Flight Model MFG CO E-mail:info@flight-model.com / flight_model@126.com Web: http://www.flight-model.com/product/eindex.asp http://flight-model.preview.alibaba.com/...
