Wing Span:70in/1780mm;
Wing Area:61sq.dm;
Length:62.9in/1600mm
CAUTION : this plane is not a toy!
Before use , please carefully read this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
performance to full extent .
●Assemble this kit only in places out of children's reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
Flying Weight:3600g;
Radio:4channels 5servos;
Engine:26-28CC GAS;
P1
Advertisement
Related Manuals for Flight Model Funtama 100
Summary of Contents for Flight Model Funtama 100
- Page 1 Wing Span:70in/1780mm; Flying Weight:3600g; Wing Area:61sq.dm; Radio:4channels 5servos; Length:62.9in/1600mm Engine:26-28CC GAS; CAUTION : this plane is not a toy! Before use , please carefully read this manual. ●First-time builders should seek advice from people having building experience in order to assemble the model correctly and to produce its performance to full extent .
-
Page 2: Kit Contents
KIT CONTENTS... -
Page 3: Main Wings
MAIN WINGS AB GLUE Connect the aileron and main wing with horns. The finished picture as shown. Pay attention to glue firmly. Cut away covering film for the servo. - Page 4 Install the tri-horn and servo arm with pushrod as shown. Measure the length of the extention . Pull out the extention from the rib of the main wing.
- Page 5 Find out the holes in each sides of fuselage, then cut the film. Connect the main wings and the fuselage with joiner. Also pull the extension into the fuselage. Fixup the wings with nylon screws as shown.
-
Page 6: Main Landing Gear
MAIN LANDING GEAR Install the wheel with screw and collars as shown. Fixup the wheel to the landing gear by screw. Use two TP screws to fix the wheel cover to the landing gear. -
Page 7: Tail Wheel
Install the main landing gear on the bottom of the fuselage. TAIL WHEEL Find and cut the hole for stabilizer and also the servo holes. Cut away the film along the edges, and glow the stabilizer to the fuselage. - Page 8 Cut the rudder film along the edges, and glue the rudder to the fuselage. Securely glue up and soaked up the hinge with instant glue. Bend the tail landing gear to fit for the rudder and insert it into the rudder.
- Page 9 Glue the rudder to the fuselage. Glow the tail landing gear to the rudder securely. Install the tail wheel, and fasten the presser of the tail wheel to the stabilizer by screws.
- Page 10 ELEVATOR AND RUDDER Insert elevator to the tailplane with U shape wire. Connect the control horn to the linkage of the servo. Tighten the second loop through the brass swage tube.
- Page 11 Crimp the brass tube with a crimping tool or pliers. Connect the parts as shown. Push rods Rudder servo arm...
- Page 12 Install rudder pushrod. ENGINE Gather the MLD engine and spare parts as shown. The finished picture as shown. Pay attention to:you have DLE and MLD for choice.
- Page 13 Install the DLE 30CC as shown.
- Page 14 Place the hatch. Use two screws to secure it firmly. FUEL TANK...
- Page 15 CG POSITION & CONTROL THROWS MEASUREMENT...
- Page 16 FINISHED PICTURE Flight Model MFG CO . ADD:No.10,Fu Ning Street,Xian Xi Industrial,Chang An Town,Dong Guan City,Guang Dong Province,China Tel: +86-769-85070618 / +86-769-81627996 / +86-769-89790965 Fax: +86-769-85091868 E-mail:info@flight-model.com / flight_model@126.com Web: http://www.flight-model.com/product/eindex.asp http://flight-model.preview.alibaba.com/...
