Wing Span:66.9in/1700mm;Flying Weight:3000g;
Wing Area:50sq.dm;
Length:61.8in/1570mm;
Caution:this plane is not a toy!
Before use ,please carefully read this manual.
● First-time builders should seek advice from people having building experience in order
to assemble the model correctly and to produce its Performance to full extent.
● Assemble this kit only in places out of children's reach!
● Take enough safety percautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
● Always keep this instruction manual ready at hand for quick reference,even after
completing the assembly.
Radio:4Channels 5Servos;
Engine:2C-60,4C-91;

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F131 Kelly F1 60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Flight Model F131 Kelly F1 60

  • Page 1 Wing Span:66.9in/1700mm;Flying Weight:3000g; Wing Area:50sq.dm; Radio:4Channels 5Servos; Length:61.8in/1570mm; Engine:2C-60,4C-91; Caution:this plane is not a toy! Before use ,please carefully read this manual. ● First-time builders should seek advice from people having building experience in order to assemble the model correctly and to produce its Performance to full extent. ●...
  • Page 2: Kit Contents

    KIT CONTENTS AILERON SERVO INSTALLATION Cut away covering film for the servo.
  • Page 3 Glue the servo to prepared servo plywood,then put the servo into the servo hole. Pull out the servo extention from main wing. Fixup the servo by the screws, then adjust the horn and servo arm. Fix the horn in place firmly.
  • Page 4: Main Wing Installation

    MAIN WING INSTALLATION Find out the horns in each sides of the fuselage, then cut the film. Insert the joiner into the fuselage,and find the left and right main wing in the right position. Fixup the wings with plastic Plastic bolt bolts on both sides.
  • Page 5: Elevator & Rudder Servo Installation

    ELEVATOR & RUDDER SERVO INSTALLATION Find out and Cut off the film in the bottom of the fuselage. Cut the film along the edge of rectifier board . Glue the Rectifier board to the bottom of the fuselage. Find and cut the hole for stabilizer.
  • Page 6 Insert the U shape wire as shown. Assemble the elevators with the U shape wire. ADJUSTMENT...
  • Page 7 Apply AC glue to the hinges. Rudder Glue the verticle fin to the fuselage. Assemble the elevator control horn. Assemble the rudder control horn.
  • Page 8: Tail Wheel Installation

    Rudder servo TAIL WHEEL INSTALLATION Tail landing gear as shown. Amount the alumiume street to the tail fuselage. MAIN LANDING GEAR INSTALLATION Screw the wheel to the landing gear. Be assured that the screw is fixed up.
  • Page 9: Engine Installation

    Install the wheel cover, and fix it up to landing gear with TP screw. Fixup the landing gear strut to fuselage with 3 bolts. ENGINE INSTALLATION Line up the template with the firewall thrust lines and mark the location of the engine mounting holes.
  • Page 10: Fuel Tank Installation

    If use 4cycle 91 size. Install the engine mount on both sides with four 3mm screws. If use 2cycle 60 size. Use the same method to this size engine. The length from Proppler to firework is 125MM. FUEL TANK INSTALLATION Install the trottle servo as shown.
  • Page 11: Cowl Installation

    Put the fuel tank into the fuselage, and fixup it with belt. Fuel tank detail assembly picture as shown. COWL INSTALLATION Install the cowling with 4pcs TP screws.
  • Page 12: Canopy Installation

    CANOPY INSTALLATION Assemble the movable canopy. Make sure it is securitly Glue the plastic decoration on both sides of the head. CONTROL THROWS & CG POSITION...
