Wing Span:89in/2261mm;
Wing Area:63.6sq.dm;
Length:63in/1600mm;
CAUTION : this plane is not a toy and should be kept away
children under 16 years of age! Before use , please carefully read
this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
performance to full extent .
●Assemble this kit only in places out of children's reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
Flying Weight:5800-6200g;
Radio:6Channel 8Servos;
Engine:30-35CC Gas
P.1
Advertisement
Related Manuals for Flight Model F168 PZL-104 WILGA
Summary of Contents for Flight Model F168 PZL-104 WILGA
- Page 1 Wing Span:89in/2261mm; Flying Weight:5800-6200g; Wing Area:63.6sq.dm; Radio:6Channel 8Servos; Length:63in/1600mm; Engine:30-35CC Gas CAUTION : this plane is not a toy and should be kept away children under 16 years of age! Before use , please carefully read this manual. ●First-time builders should seek advice from people having building experience in order to assemble the model correctly and to produce its performance to full extent .
- Page 2 MAIN WING Connect the aileron and the main wing by hinges. Be sure to apply instant type glue to both sides of each hinges. Install the aileron horns in place with AB glue Align the holes in the horns Cut the servo holes on the bottom of the main wings...
-
Page 3: Stabilizer And Elevator
Install the servo in the servo-tray as shown Put the servo into the hole Screw the servo to wing Link the servo arms and tri-horns with pushrod STABILIZER AND ELEVATOR Fix up the stabilizer and rudder with hinges and AB glue. - Page 4 install vertail fin as shown Connect the rudder to the fuselage the horns into the original design hole location by hinges and AB glue. install the elevator pushrod as shown...
- Page 5 Screw the elevator to the fuselage Be assured that the screw is fixed up. Connect the elevator to the fuselage the horns Tail wheel Assemble elevator servo as shown. Gather the tail wheel and screw...
-
Page 6: Main Landing Gear
Ensure it has been totally screwed into the fuselage. attach the servo arm to the ruddert servo as shown As shown in picture, This is finished for the servo. MAIN LANDING GEAR... - Page 7 Fix up the landing gear on the fuselage bottom with screws. Gather the landing gear, wheels and screw as shown. Cut the hole for hinge For landing gear install the landing gear Use screws to fix up the fuselage.
- Page 8 The finished photo as shown. FUEL TANK Install the fuel tank into the fuselage, and fixup it with belt. Install the fuel tank mounting ties under the fuel tank floor.
- Page 9 Install the battery,receiver and switch in place as shown. ENGINE Drill the engine mounting holes as the board provided Install the engine mount on both sides with four screws...
- Page 10 Install the propeller and spinner as shown CANOPY AND COWL Install the canopy into the fuselage as shown Install the side window into the fuselage as shown P.10...
- Page 11 The canopy in to the fuselage Installed front window as shown Connect the main wings and the fuselage with joiner. Install the above window P.11...
- Page 12 CG POSITION & CONTROL THROWS 6.14in THE FINISHED PHOTO P.12...
- Page 13 Another scheme for choice Dong Guang Flight Model CO.,Ltd ADD:No.10,Fu Ning Street,Xian Xi Industrial,Chang An Town, DongGuan City,Guang Dong Province,China Tel: +86-769-85070618 / +86-769-89790965 Fax: +86-769-85091868 E-mail:info@flight-model.com Web: http://www.flight-model.com/product/eindex.asp http://flight-model.preview.alibaba.com/ P.13...
