Flight Model Taylorcraft-90 Assemble Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Wing Span:87.4in/2222mm;
Wing Area:69.2sq.dm;
Length:56.4in/1433mm;
CAUTION : this plane is not a toy!
Before use , please carefully read this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
performance to full extent .
●Assemble this kit only in places out of children's reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
Flying Weight:3000g;
Radio:6Channels 4Servos;
Outer Runner Brushless Motor:5065
P1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Taylorcraft-90 and is the answer not in the manual?

Questions and answers

Related Manuals for Flight Model Taylorcraft-90

Summary of Contents for Flight Model Taylorcraft-90

  • Page 1 Wing Span:87.4in/2222mm; Flying Weight:3000g; Wing Area:69.2sq.dm; Radio:6Channels 4Servos; Length:56.4in/1433mm; Outer Runner Brushless Motor:5065 CAUTION : this plane is not a toy! Before use , please carefully read this manual. ●First-time builders should seek advice from people having building experience in order to assemble the model correctly and to produce its performance to full extent .

  • Page 2: Main Wings

    MAIN WINGS Cut away covering film for the servo. Install the servo to the servo cover. Put the servo cover in the right position,then fixup it.
  • Page 3 Install the servo cover to the bottom of the wings,and Assemble aileron、servo arm and pushrod. Insert the main wings with joiner,then screw them by nylon screws. Assemble the plastic cover by screws on the top of the wings.

  • Page 4: Tail Wheel

    Install the wing supports with screws. Make sure they are in right positions. The blind nuts in the wing. TAIL WHEEL Cut off the film for the vertical fin. Insert the vertical fin and glue the rudder to the vertical fin .
  • Page 5 Install the tail wheel as shown. RUDDER AND ELEVATOR Cut off the film for elevator servo installation. Adjustable Tri-horns...
  • Page 6 Install the elevator servo. Fixup the adjustable tri-horn then link the servo and tri-horn with pushrod. Inatall a servos ectention onto the elevator servo.Either tie the srco leads together,or use a connector to secure the extension to prevent it from coming loose during flight. THE MOTOR INSTALLED Install the motor to the four adapter and use screws to...

  • Page 7: Throttle Servo

    THROTTLE SERVO Assemble the receiver and receiver battery as shown. UNDERCARRIAGE Install two wheels to the undercarriage as shown. Install the undercarriage to the bottom of the fuselage.
  • Page 8 Permanently tighten the axle to the gear strut by wrenches. Finished photo as shown. COWLING Install the cowling with screws which factory provided. CG POSITION & CONTROL THROWS...
  • Page 9 FINISHED PHOTO...
  • Page 10 Flight Model CO.,LTD ADD:No.10,Fu Ning Street,Xian Xi Industrial,Chang An Town,Dong Guan City,Guang Dong Province,China Tel: +86-769-85070618 / +86-769-81627996 / +86-769-89790965 Fax: +86-769-85091868 E-mail:info@flight-model.com / flight_model@126.com Web: http://www.flight-model.com/product/eindex.asp http://flight-model.preview.alibaba.com/...
  • Page 14 ts in...
