IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
For assembly see instructions in carton 500 943.
home
500 941
3-
Kitchen Island
styles Customer Service: www.homestylesfurniture.com,
servicedesk@homestylesfurniture.com,
A.
Top Unit
1 pc.
B.
Leaf Top
1 pc.
3-
888-680-7460
