Home Styles 5004 692 Assembly Instructions

Pantry

Advertisement

Quick Links

88 5004 692
Pantry
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.

Part List

A.
Top
1 pc.
G.
Base
1 pc.
H.
Base
1 pc.

Hardware List

Cam Lock
24 pcs.(+1 extra)
Cam Lock Screw
24 pcs.(+1 extra)
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
B.
Side Panel
2 pcs.
I.
Shelf
4 pcs.
servicedesk@homestyles-furniture.com
D.
Back Stretcher
4 pcs.
C.
Side Panel
2 pcs.
Back Stretcher
2 pcs.
J.
Door
2 pcs.
Wood Screw
for Back Panel
16 pcs. (+1 extra)
Adjustable Pin
16 pcs. (+2 extra)
Tools recommended for assembly : Level
E.
F.
Back Panel
4 pcs.
K.
Door
2 pcs.
Machine Screw
4 pcs.
Door
Pull Handle
4 pcs.
Revised date : 15May2012
