Connecting Your Projector
1
2
18
17
16
1
Composite video connector
2
S-video connector
3
VGA-A output
(monitor loop-through)
4
VGA-A input (D-sub) connector
5
VGA-B input (D-sub) connector
6
HDMI connector
7
USB remote connector
8
RJ45 connector
9
Antenna connector
CAUTION:
Safety Instructions as described on page 7.
3
4
15
14
13
12
Before you begin any of the procedures in this section, follow the
5
6
11
10 Security cable slot
11 Audio output connector
12 Audio-B input connector
13 Audio-A input connector
14 Audio-C right-channel input
connector
15 Power cord connector
16 Audio-C left-channel input
connector
17 RS232 connector
18 +12V DC out connector
Connecting Your Projector
2
7
8
9
10
9
