Dell™ M210X Projector
User's Guide
Downloaded From projector-manual.com DELL Manuals

Advertisement

   Also See for Dell M210X

   Related Manuals for Dell M210X

   Summary of Contents for Dell M210X

  • Page 1

    Dell™ M210X Projector User’s Guide Downloaded From projector-manual.com DELL Manuals...

  • Page 2

    Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; DLP and DLP logo are trademarks of T...

  • Page 3: Table Of Contents

    ....Adjusting Projection Image Size ......Contents Downloaded From projector-manual.com DELL Manuals...

  • Page 4

    ......... Contents Downloaded From projector-manual.com DELL Manuals...

  • Page 5: Your Dell Projector

    Your Dell Projector Your projector comes with all the items shown below. Ensure that you have all the items, and contact Dell™ if anything is missing. Package Contents Power cable 1.8m VGA cable (VGA to VGA) Carrying case Remote control CD User’s Guide &...

  • Page 6: About Your Projector

    Ensure the projector operates between ambient temperatures (5ºC to 35ºC). Do not try to touch the ventilation outlet as it can become very hot after the projector has been turned on or immediately after it is turned off. Your Dell Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 7

    Do not place any objects near or in front of the projector or cover its lens while the projector is on as the heat may cause the object to melt or burn. NOTE: For more information, see the Safety Information that is shipped with your projector. Your Dell Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 8: Connecting Your Projector

    HDMI connector Security cable slot S-video connector Power cord connector Composite video connector CAUTION: Before you begin any of the procedures in this section, follow the Safety Instructions as described on page 6. Connecting Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 9: Connecting To A Computer

    The USB cable is not provided with your projector. NOTE: The USB cable must be connected if you want to use the Page Up and Page Down features on the remote control. Connecting Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 10: Connecting A Dvd Player

    Connecting a DVD Player Using an S-video Cable Power cord S-video cable NOTE: The S-video cable is not shipped with your projector. You can purchase the S-Video extension (50 ft/100 ft) cable on the Dell website at dell.com. Connecting Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 11: Connecting A Dvd Player Using A Composite Video Cable

    Power cord Composite video cable NOTE: The Composite Video cable is not shipped with your projector. You can purchase the Composite Video Extension (50 ft/100 ft) cable on the Dell website at dell.com. Connecting Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 12: Connecting A Dvd Player Using A Component Video Cable

    NOTE: The VGA to Component Video cable is not shipped with your projector. You can purchase the VGA to Component Video Extension (50 ft/100 ft) cable on the Dell website at dell.com. Connecting Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 13: Connecting A Dvd Player Using An Hdmi Cable

    Connecting a DVD Player Using an HDMI Cable Power cord HDMI cable NOTE: The HDMI cable is not shipped with your projector. Connecting Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 14: Using Your Projector

    The message disappears after 5 seconds or you can press the Menu button to clear it. Press the Power button again. The cooling fans continue to operate for 120 seconds. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 15: Adjusting The Projected Image

    Press the Elevator button. Lower the projector, and then release the button to lock the elevator foot into position. Elevator button Elevator foot (Angle of tilt: 0 to 9.5 degree) Tilt adjustment wheel Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 16: Adjusting The Projector Zoom And Focus

    Rotate the zoom tab to zoom in and out. Rotate the focus ring until the image is clear. The projector focuses at distances ranging between 3.28 ft to 39.37 ft (1 m to 12 m). Zoom tab Focus ring Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 17: Adjusting Projection Image Size

    Adjusting Projection Image Size 302.8"(769.11 cm) 227"(576.58 cm) 177"(449.58 cm) 126"(320.04 cm) 76"(193.04 cm) 25"(63.50 cm) 22.89" (58.14 cm) 3.28'(1.0m) Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 18: Using The Control Panel

    (201 cm) (281 cm) (361 cm) (481 cm) Distance 3.28' 9.84' 16.40' 22.97' 29.53' 39.37' (1.0m) (3.0m) (5.0m) (7.0m) (9.0m) (12.0m) * This graph is for user reference only. Using the Control Panel Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 19

    Press to synchronize the projector to the input source. NOTE: Auto Adjust does not operate if the on-screen display (OSD) is displayed. IR Receiver Point the remote control towards the IR receiver and press a button. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 20

    (OSD) Menu items. Press to toggle through Analog RGB, Composite, Component (YPbPr via VGA), HDMI, and S-video sources when multiple sources are connected to the projector. 10 Enter Press to confirm the selection item. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 21: Using The Remote Control

    14 and "Turning Your Projector Off" on page 14. Enter Press to confirm the selection. Right Press to navigate through the On-Screen Display (OSD) Menu items. Down Press to navigate through the On-Screen Display (OSD) Menu items. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 22

    17 Keystone adjustment Press to adjust image distortion caused by tilting the projector (+40/-35 degrees). 18 Source Press to switch between Analog RGB, Composite, Component (YPbPr, via VGA), HDMI, and S-video sources. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 23

    Press to synchronize the projector with the input source. Auto adjust does not operate if the OSD is displayed. 20 Keystone adjustment Press to adjust image distortion caused by tilting the projector (+40/-35 degrees). Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 24: Installing The Remote Control Batteries

    Insert the batteries and align their polarity correctly according to the marking in the battery compartment. NOTE: Avoid mixing different types of batteries or using new and old batteries together. Slip the battery cover back. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 25: Operating Range With Remote Control

    Operating Range With Remote Control Angle Operating range Angle ±45° Distance 10m/32.8feet Angle NOTE: Actual operating range may slightly differ from the diagram. Weak batteries will also prevent the remote control from properly operating the projector. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 26: Using The On-screen Display

    Main Menu AUTO-ADJUST Auto Adjust automatically adjusts the projector's Frequency and Tracking in PC mode. While Auto Adjustment is in progress, the following message appears on the screen: Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 27: Input Select

    Composite Video input. OMPOSITE IDEO HDMI—Use to enable or disable HDMI input. NOTE: You cannot disable your current input source. At anytime, a minimum of two input sources have to be enabled. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 28: Picture (in Pc Mode)

    —Allows you to optimize the display image: Presentation, Bright, IDEO MODE Movie, sRGB (provides more accurate color representation), and Custom (set your preferred settings).If you adjust the settings for Brightness, Contrast, Saturation, Sharpness, Tint, and Advanced the projector automatically switches Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 29

    When you adjust the values in the Color Adjust menu, the Custom mode is activated. The values are saved in the Custom mode. —Allows you to manually adjust the colors red, green, and USTOM OLOR DJUST blue. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 30: Display (in Pc Mode)

    —Press to activate Zoom Navigation AVIGATION menu. to navigate projection screen. —Press to move the image to the left and to move the ORIZONTAL OSITION image to the right. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 31: Display (in Video Mode)

    Zoom menu. Select the area to zoom and press to view zoomed image. Adjust the image scale by pressing press to view. —Press to activate Zoom Navigation AVIGATION menu. to navigate projection screen. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 32: Lamp

    —Displays the operating hours since the last lamp timer reset. —Select Yes to reset the lamp timer. ESET SET UP The Set Up menu allows you to adjust settings for Language, Projector Mode, Keystone, and 3D Display. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 33

    3D Sync Invert—If you see a discrete or overlapping image while wearing DLP 3D goggles, you may need to execute 'Invert' to get best match of left/right image sequence to get the correct image. (For DLP 3D goggles) Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 34: Information

    — Select and press to activate menu settings. The menu ETTINGS settings consists of the following options: — Allows you to change the position of the OSD menu on OSITION the screen. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 35

    To capture a full image, ensure the input signal that is connected to the projector is 1024 x 768 resolution. — Select Dell to use the Dell logo as wallpaper. Select Captured to CREEN set the captured image as wallpaper.

  • Page 36

    The projector will take a longer time to turn on if you try to power on immediately. Its cooling fan will run at full speed for about 30 seconds to stabilize the internal temperature. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 37

    First time password input request: Go to Others menu, press and then select Password to Enable the password setting. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 38

    If you have entered an incorrect password, you will be given another 2 chances. After the three invalid attempts, the projector will automatically turn off. NOTE: If you forget your password, contact DELL™ or qualified service personnel. To disable the password function, select Off to disable the function.

  • Page 39

    — Select On to enable close caption and activate the closed LOSED APTION caption menu. Select an appropriate closed captions option: CC1, CC2, CC3, and CC4. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 40

    Test Pattern 2: — Select and press to reset all settings to its factory default, the ACTORY ESET warning message below appears. Reset items include both computer sources and video source settings. Using Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 41: Troubleshooting Your Projector

    Troubleshooting Your Projector If you experience problems with your projector, see the following troubleshooting tips. If the problem persists, contact Dell™. See Contacting Dell™ on page 53. Problem Possible Solution No image appears on the • Ensure that the lens cap is removed and the screen projector is turned on.

  • Page 42

    Press the Auto Adjust button on the incorrectly displayed image remote control or the control panel. If you are using a Dell™ portable computer, set the resolution of the computer to XGA (1024 x 768): Right-click the unused portion of your ®...

  • Page 43

    POWER button for 10 seconds. TEMP light is solid amber The projector has overheated. The display automatically shuts down. Turn the display on again after the projector cools down. If the problem persists, contact Dell™. Troubleshooting Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 44

    POWER button for 10 seconds. Please wait for about 5 minutes and try to power up again. If the problem persists, contact Dell™. The OSD does not appear on Try to press the Menu button on the panel for the screen 15 seconds to unlock the OSD.

  • Page 45: Guiding Signals

    Unplug the AMBER AMBER BLUE power cord after three minutes and then Flashing Flashing turn on the projector. If this problem persists, contact Dell. Troubleshooting Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 46

    Lamp is defective. Replace the lamp. AMBER Lamp module Lamp module connection may be connection disrupted. Check the lamp module and AMBER failed ensure that it is properly installed. If the Flashing problem persists, contact Dell. Troubleshooting Your Projector Downloaded From projector-manual.com DELL Manuals...

  • Page 47: Changing The Lamp

    Replace the lamp when the message "Lamp is approaching the end of its useful life in the operation. Replacement suggested! www.dell.com/lamps" appears on the screen. If this problem persists after replacing the lamp, contact Dell™. For more information, see Contacting Dell™on page 53. CAUTION: Use an original lamp to ensure safe and optimal working condition of your projector.

  • Page 48

    LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS. FOR MORE INFORMATION, GO TO WWW.DELL.COM/HG OR CONTACT THE ELECTRONIC INDUSTRIES ALLIANCE AT WWW.EIAE.ORG. FOR LAMP SPECIFIC DISPOSAL INFORMATION CHECK WWW.LAMPRECYCLE.ORG.

  • Page 49: Specifications

    Eco mode: 166W ± 10% @ 110Vac Power saving mode: <12W Standby mode: < 1W Audio 1 speaker x 1 watt RMS Noise Level 39 dB(A) Normal mode, 32 dB(A) Eco mode Weight 2.6 lbs (1.18 kg) Specifications Downloaded From projector-manual.com DELL Manuals...

  • Page 50

    (Blue). Variable audio output: One 3.5 mm stereo mini phone jack (Green). USB port: One USB slave for remote support. Lamp OSRAM 165 W user-replaceable lamp (up to 5000 hours in eco mode) Specifications Downloaded From projector-manual.com DELL Manuals...

  • Page 51

    Usage of a projector in stressful conditions which may include dusty environments, under high temperatures, many hours per day and abrupt powering-off will most likely result in a lamp’s shortened operating life span or possible lamp failure. Specifications Downloaded From projector-manual.com DELL Manuals...

  • Page 52

    1280 x 960 85.002 85.938 148.500 1920 x 1080 60.000 67.500 148.500 1400 x 1050 74.867 82.278 156.000 1280 x 1024 85.024 91.146 157.000 1440 x 900 84.842 80.430 157.000 1600 x 1200 60.000 75.000 162.000 Specifications Downloaded From projector-manual.com DELL Manuals...

  • Page 53: Contacting Dell

    Dell product catalog. Dell™ provides several online and telephone-based support and service options. Availability varies by country and product, and some services may not be available in your area. To contact Dell for sales, technical support, or customer service issues: Visit support.dell.com.

  • Page 54: Appendix: Glossary

    ANSI contrast ratio. Full On/Off contrast is always a larger number than ANSI contrast for the same projector. Glossary Downloaded From projector-manual.com DELL Manuals...

  • Page 55

    525 lines at 30 frames per second. PAL — Phase Alternating Line. A European broadcast standard for video and broadcasting, with a video format of 625 lines at 25 frames per second. Glossary Downloaded From projector-manual.com DELL Manuals...

  • Page 56

    Zoom Lens Ratio — Is the ratio between the smallest and largest image a lens can project from a fixed distance. For example, a 1.4:1 zoom lens ratio means that a 10 foot image without zoom would be a 14 foot image with full zoom. Glossary Downloaded From projector-manual.com DELL Manuals...

  • Page 57

    Elevator button 6 Cable 12 Focus ring 6 Connecting with a Composite IR receiver 6 Cable 11 Lens 6 Connecting with an HDMI Zoom tab 6 Cable 13 Connecting with an S-video Menu Position 34 Index Downloaded From projector-manual.com DELL Manuals...

  • Page 58

    Projection Distance 49 Powering Off the Projector 14 Projection Lens 49 Powering On the Projector 14 Projection Screen Size 49 Uniformity 49 Video Compatibility 49 Quick Shutdown 36 Weight 49 support contacting Dell 53 Index Downloaded From projector-manual.com DELL Manuals...

  • Page 59

    53 Test Pattern 40 Troubleshooting 41 Contact Dell 41 Volume 36 Index Downloaded From projector-manual.com DELL Manuals...
