Geokon 6101 Instruction Manual

Portable tiltmeter

Advertisement

Quick Links

Instruction Manual
Model 6101
MEMS
Portable Tiltmeter
No part of this instruction manual may be reproduced, by any means, without the written consent of Geokon, Inc.
The information contained herein is believed to be accurate and reliable. However, Geokon, Inc. assumes no responsibility
for errors, omissions or misinterpretation. The information herein is subject to change without notification.
Copyright © 2010 by Geokon, Inc.
(Doc Initial 9/10)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6101 and is the answer not in the manual?

Questions and answers

Summary of Contents for Geokon 6101

  • Page 1 MEMS Portable Tiltmeter No part of this instruction manual may be reproduced, by any means, without the written consent of Geokon, Inc. The information contained herein is believed to be accurate and reliable. However, Geokon, Inc. assumes no responsibility for errors, omissions or misinterpretation. The information herein is subject to change without notification.
  • Page 3 The buyer's sole remedy for any breach of this agreement by Geokon, Inc. or any breach of any warranty by Geokon, Inc. shall not exceed the purchase price paid by the purchaser to Geokon, Inc. for the unit or units, or equipment directly affected by such breach.
  • Page 5: Table Of Contents

    TABLE of CONTENTS 1. SPECIFICATIONS MODEL 6101 MEMS PORTABLE TILTMETER ............1 VOLTAGES IN EXCESS OF 18V WILL DAMAGE THE CIRCUITRY AND ARE TO BE AVOIDED... 1 2. INTRODUCTION ............................... 2 2.1 D ..............................2 ESCRIPTION 3. INSTALLATION ..............................2 4.
  • Page 6: Specifications Model 6101 Mems Portable Tiltmeter

    1. Specifications Model 6101 MEMS Portable Tiltmeter__________ ±15° Range +/- 4 Volts DC (Nominal) Output at +/- 15º 9 to18 Volts DC Input Supply Voltage 25 mA Input Supply Current ± 2 arc seconds (+/- 0.05mm/m) Resolution ± 3 arc seconds.
  • Page 7: Introduction

    The output of the Geokon Model 6101 MEMS tiltmeter is equal to +/- 4 volts at +/- 15°. When used with a GK- 603, or GK-604 readout box, set to a gage factor of approx 0.62 (the exact gage factor is shown on the calibration sheet), the display will be 20,000 sin ...
  • Page 8: Taking Readings

    For Horizontal installations point the Peg #1 in the same direction as the expected tilt 4. Taking Readings ________________________________________________ Connect the sensor to the readout and check to see that the system is operating. Clean all dirt from both the sensor and the tiltplate.
  • Page 9: Data Recording And Reduction

    Peg 1 reading = 82 and Peg 3 reading = –99 DIFF = (82) – (–99) = +181 The conversion of this difference to degrees of angle is done as follows: Reading with either the Geokon GK601 or GK 603 readouts DIFF –1 –4...
  • Page 10 [ or x 10 for Sinco metric tiltmeters only.] [or, in mm/m, or thousands of inches/inch tilt= DIFF/50] Assuming that the present example is from a Geokon metric tiltmeter: –4 –1 The tilt in the Peg 1 direction is x 10 = 0.148...
  • Page 11: Troubleshooting

    A tiltplate tilted at an angle and located on a stable surface can be read periodically to check the calibration of the instrument. The sensor itself should not be opened in the field and if the unit fails to work it should be returned to Geokon for repair.
  • Page 12 Figure 1 Measurements in the Vertical Plane Plus End Minus End...
  • Page 14 Figure 2 Measurements in the Horizontal Plane Figure 3 Tiltmeter Data Sheet...
