- Page 1 Installation and User's Guide ECON L09 IP x4 Druck-Nr. 29343281en 37.06...
- Page 2 Installation guide for power control unit 9 kW The power control unit is delivered equipped for a voltage of 380 - 400 V AC 3N with a maximum breaking capacity of 9 kW and with a safety shutdown in connection with our sauna control unit as standard.
- Page 3 If the sauna cabin is not equipped with cable conduits for the connecting lines, these lines must be laid directly onto the cabin wall, where they will be visible. For this purpose, the three mounting holes must be pre-drilled, as shown in Illust. 3. Because the connecting lines must be laid between the capacitor and the cabin wall in this type of installation, for practical...
- Page 4 Direct warranty processing with our service department is in this case not possible. Equipment start-up date: Stamp and signature of the authorized electrician: Service address: EOS-Werke Günther GmbH Adolf-Weiß-Str. 43 35759 Driedorf-Germany tel +49 (0)2775- 82 240 fax +49 (0)2775- 82 455 servicecenter@eos-werke.de...
-
Page 5: Wiring Diagram
Wiring diagram Saunaheater Power supply Control cable Caution! Maximum phase load 3 kW per phase...
