(5) Alarm / power LEDs
Description of LEDs:
LED
Power indicator, when the drive is powered, this LED is lit;
Green LED
when the power is cut off, the LED turns off.
Fault alarm LED; when a failure occurs, the yellow LED is lit
Yellow LED
(6) DIP switch
Q2BYG808MD/806DK stepper drive uses 8‐bit DIP switch S1 to set the output
current, subdivision precision and operation mode; set by 4‐bit DIP switch S2.
The front view of DIP switch is as follows:
Fig. (2) Front View of DIP Switch
1) Current setting (Ipeak): SW1‐SW3
Ipeak(A) Ipeak(A)
(806DK)
(808MD)
3.0
2.0
4.0
3.0
4.2
3.5
5.2
4.0
5.6
4.2
6.2
5.2
7.0
5.6
8.0 6.2
2) Running mode setting SW4
SW4 Mode
Subdivision operating
OFF
mode
ON Self‐test mode
Q2BYG808MD Driver User's Manual
content
SW1 SW2
OFF OFF
ON OFF
OFF ON
ON ON
OFF OFF
ON OFF
OFF ON
ON ON
Description
Move corresponding angle according to
the number of subdivisions every step
Run at 30rpm automatically in 32
subdivisions, change the magnification
by changing the subdivision speed
-15-
SW3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
