Differential
Output signal
output
Protection
function
Monitoring
functions
Built‐in
functions
Communication
functions
Indication
functions
1.5 Applications
It is suitable for a variety of small and medium sized automation equipment and instruments,
such as: dispenser, marking machine, cutting machine, engraving machine, labeling machine,
plotter, automatic assembly equipment, numerical control machine tool, etc. It has
outstanding application effect in the equipment that users expect low vibration, low noise
and high‐speed.
For long time running that stall situation should be monitored, such as wood carving, 806DK
and 808MD have stall detection function without encoder.
Q2BYG808MD Driver User's Manual
Position home Z, stall alarm ALM
Overcurrent, overvoltage, undervoltage, stall and
other alarms
Current, speed, bus voltage, position, operating mode,
etc.
Achieve communication with PC via RS232 or RS485,
and achieve parameter modification and system
running status monitoring (RS232 and RS485 can't be
used simultaneously. You can use DIP switch to select
the desired communication.)
Red (alarm), green (working) indicator
