Summary of Contents for Batca C-2
- Page 1 Revision 5 June 2009 Mid Row/ Lat Pull Owner’s Manual Record Serial Number Here Batca Fitness Systems Tel. (919) 255-1233 Date of Purchase www.batcafitness.com...
- Page 2 Instructions Congratulations on the purchase of your new Batca C-2. This gym will provide you with a lifetime of enjoyment to meet your strength training needs. Batca Fitness Systems strives to build the best quality gyms and to package these gyms in such a way to avoid any damage during shipping.
- Page 3 1 1/4” Grip Cap • 9/16” Wrench BFH-50632 1 1/4” Grip Collar • 3/4” Wrench BFH-50207 1” Grip Cap • BFH-50208 1” Grip Collar 9/16” Ratchet BFH-50262 Silicone Gel Pack • Allen Wrench Set • Tape Measure www.batcafitness.com C-2 Owner’s Manual...
- Page 4 Bolt Length Note: Bolt length is measured from the underside of the head of the bolt. Mid Row/Lat Pull Combo C-2 Owner's Manual...
- Page 5 C-2 Owner’s Manual...
- Page 6 Mid Row/Lat Pull Combo C-2 Owner's Manual...
- Page 7 C-2 Owner’s Manual...
- Page 8 Figure 1 Item # Part # Description BFH-50255 Rubber Foot BFM-10377 Mid Row Base BFM-10383 Anti-Tip BFM-10405 Cage BFH-50146 3/8" Flat Washer (Black) BFH-50157 3/8"-16 Nylock (Black) BFH-50130 HCS 3/8"-16 x 4 1/4" P5 Mid Row/Lat Pull Combo C-2 Owner's Manual...
- Page 9 Figure 2 Item # Part # Description BFM-10430 Weight Plate BFM-50529 Rubber Donut BFM-10413 3/4” 10lb Top Plate BFM-50633 Guide Rod All Flat Washers and Nylocks are 3/8” unless otherwise noted. BFM-51173 Magnetic Weight Stack Pin www.batcafitness.com C-2 Owner’s Manual...
- Page 10 BFM-10438 Guide Rod Pulley Holder BFM-10131 Bar Catch Right BFM-10130 Bar Catch Left BFH-50202 3/4" Pulley Spacer BFH-50126 HCS 3/8"-16 x 3 1/4" P5 All Flat Washers and Nylocks are 3/8” unless otherwise noted. Mid Row/Lat Pull Combo C-2 Owner's Manual...
- Page 11 3/8"-16 Nylock (Black) Figure 4 BFH-50129 HCS 3/8"-16 x 4" P5 BFH-50253 Beveled Leveler BFH-50149 3/8"-16 Jam Nut (Zinc) All Flat Washers and Nylocks are 3/8” unless otherwise noted. BFH-50126 HCS 3/8"-16 x 3 1/4" P5 www.batcafitness.com C-2 Owner’s Manual...
- Page 12 HCS 3/8"-16 x 3 3/4" P5 BFM-50247 1/2" Spacer BFM-51279 1 1/4” Grip Sleeve BFH-50633 1 1/4” Grip Cap BFH-50632 1 1/4” Grip Collar All Flat Washers and Nylocks are 3/8” unless otherwise noted. Mid Row/Lat Pull Combo C-2 Owner's Manual...
- Page 13 3/8" Flat Washer (Black) BFH-50157 3/8"-16 Nylock (Black) BFH-50125 HCS 3/8"-16 x 3" P5 BFH-50124 HCS 3/8"-16 x 2 3/4" P5 All Flat Washers and Nylocks are 3/8” unless otherwise noted. BFH-50121 HCS 3/8"-16 x 2" P5 www.batcafitness.com C-2 Owner’s Manual...
- Page 14 7" Upholstery Roller 3/8” Nylock. BFH-50221 3" Plastic Washer BFH-50622 Roller End Cap BFM-50433 Knee Hold Down Pipe BFH-50620 BHSCS 3/8" X 1" P5 All Flat Washers and Nylocks are 3/8” unless otherwise noted. Mid Row/Lat Pull Combo C-2 Owner's Manual...
- Page 15 BFC-10101 1 inch Chain BFH-50238 BFH-50239 Snap Ring BFU-10125 Lat Bar Pad All Flat Washers and Nylocks are 3/8” BFH-50188 Snap Hook unless otherwise noted. BFH-50207 1” Grip Cap BFH-50208 1” Grip Collar Mid Row/Lat Pull Combo C-2 Owner's Manual...
-
Page 16: Final Assembly And Troubleshooting
Clean guide rods with a lint-free cloth and apply a thin layer of silicon lubricant (Part # BFH-50262) to each guide rod. This will ensure a glass smooth performance from your weight stack. Mid Row/Lat Pull Combo C-2 Owner's Manual... -
Page 17: Cable Adjustments
Failure to route this cable correctly will void your warranty. Fine Adjustments to the cable tension can be made here. It is very important to tighten the jam nut after adjustments. www.batcafitness.com C-2 Owner’s Manual... -
Page 18: Preventive Maintenance
Preventive Maintenance Batca Fitness Systems strives to give you the very best in quality, performance and safety through carefully engineered designs and excellent workmanship. In order to maintain this high level of quality the preventative maintenance schedule below should be followed. -
Page 19: Limited Lifetime Warranty
Batca Fitness Systems warrants all of its products against defects in manufacturing, materials and workmanship under nor- mal use and service for one year from date of purchase including paint, chrome, upholstery and grips. Batca Fitness Sys- tems also warrants all cables, belts, bolts, nuts, caps, plugs, bumpers, washers, levelers, decals, gas springs and other hardware for three years after date of purchase;... -
Page 20: Layout Diagram
Layout Diagram The C-2 has a layout dimension of 3’-0” (width) x 5’-1” (length) x 7’-0” (height). There should be a minimum of 18”, preferably 24”, of working space around the entire unit. Mid Row/Lat Pull Combo C-2 Owner's Manual...
