Camera Module
Dell™ Studio™ 1569 Service Manual
Removing the Camera Module
Replacing the Camera Module
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best practices information, see the
Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION: Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell™
is not covered by your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on the back of the computer).
CAUTION: To help prevent damage to the system board, remove the main battery (see
computer.
Removing the Camera Module
1. Follow the procedures in Before You
2. Remove the battery (see Removing the
3. Remove the display assembly (see
4. Remove the display bezel (see
5. Pull the pull-tab to disconnect the camera cable from the camera module.
6. Lift the camera module off the display cover.
1 display cover
3 pull-tab
Replacing the Camera Module
1. Follow the procedures in Before You
2. Remove the new camera module from its packaging and peel off the protective adhesive liner.
3. Use the alignment posts to place the camera module on the display cover.
4. Press down on the camera module to secure it to the display cover.
5. Connect the camera cable to the connector on the camera module.
Begin.
Battery).
Removing the Display Assembly).
Replacing the Display Bezel).
2 camera module
4 camera cable
Begin.
Removing the Battery) before working inside the
