- Page 1 All manuals and user guides at all-guides.com User Manual H-PCKT-MOD Encoder Modulator 2018 Thor Fiber 2018 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com...
- Page 2 All manuals and user guides at all-guides.com H-PCKT-MOD A Note from Thor Broadcast about this Manual Intended Audience This user manual has been written to help people who have to use, integrate and to install the product. Some chapters require some prerequisite knowledge in electronics and especially in broadcast technologies and standards.
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com H-PCKT-MOD Table of Contents HDMI-M J.83B/ATSC/DVB-T/ISDB-T B ................1 ODULATOR UTTON AYOUT ............................. 1 AFETY NSTRUCTIONS ..............................2 RIMARY ..........................2 AVIGATION IN THE MENU ............................. 3 PPLICATION RAWING ..............................4 J.83B M J.83B –... -
Page 4: Hdmi-Modulator J.83B/Atsc/Dvb-T/Isdb-T Button Layout
All manuals and user guides at all-guides.com H-PCKT-MOD HDMI-Modulator J.83B/ATSC/DVB-T/ISDB-T Button Layout HDMI HDMI Signal input CVBS/ CC CVBS or Signal input Power Supply 12V DC 1A Ethernet RJ45 connector for service Micro USB PC connector for service & update... -
Page 5: Primary Use
H-PCKT-MOD Primary Use This Thor Broadcast H-PCKT-MOD handheld pocket modulator is used to feed audio-video signals through the HDMI or AV connector to inject into an existing coaxial cable network. Signals from surveillance cameras, media-players, satellite receivers or computers are fed through the input then output via RF-modulation and available to any number of receivers (TV, cable set- top-box) over long distances of coax or hybrid fiber/coax infrastructures. -
Page 6: Application Drawing
All manuals and user guides at all-guides.com H-PCKT-MOD Application Drawing Thor Fiber 2018 Tel: (800) 521-8467 Email: sales@thorfiber.com http://www.thorbroadcast.com... -
Page 7: J.83B Menu
All manuals and user guides at all-guides.com H-PCKT-MOD J.83B Menu Frequency (MHz) Output Frequency Short Name Press OK to edit Major Ch Press OK to edit Minor Ch Press OK to edit Modulation Select 64 or 256QAM RF Attenuation attenuation of the output (0-30dB attenuation>output level 100-70 dBuV) -
Page 8: Atsc - Advanced Settings
All manuals and user guides at all-guides.com H-PCKT-MOD ATSC – Advanced Settings Service ID Alphanumeric TS ID [0000-65535] Min BR Minimum bitrate,2000 kbps Max BR Maximum bitrate 24000 kbps Audio Encoder MPEG1 / AC3 / AAC PMT PID [32-8190] Video PID... -
Page 9: Dvb-T - Advanced Settings
All manuals and user guides at all-guides.com H-PCKT-MOD DVB-T – Advanced Settings Service Provider alphanumeric Network ID [0000-65535] ONID [0000-65535] TS ID [0000-65535] Service ID [0000-65535] Min BR Minimum bitrate,2000 kbps Max BR Maximum bitrate 24000 kbps Modulation QPSK / QAM16 / QAM64... -
Page 10: Isdb-T - Advanced Settings
Audio PID [32-8190] PCR PID [32-8190] Network Check and set the IP Factory Default Reset to factory settings Packing List Thor Broadcast H-PCKT-MOD 1 PC User's Manual 1 PC HDMI Cables 1 PCS Power Cord 1 PC For Further Tech Support 1-800-521-Thor(8467) support@thorfiber.com...
