Enclosure Dimensions - Altronix HubSat4Di Series Installation Manual

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of
sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Enclosure Dimensions (H x W x D approximate):
1.25"
(31.75mm)
Altronix is not responsible for any typographical errors.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty
IIHubSat4Di
- 12 -
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside.
Refer servicing to qualified service personnel.
8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm)
0.6" (15.2mm)
1.125"
(28.6mm)
1"
(25.4mm)
0.6" (15.2mm)
1"
(25.4mm)
7.25" (184.2mm)
3.625" (92mm)
6.05" (153.7mm)
6.05" (153.7mm)
5.25" (133.35mm)
(25.4mm)
I20U
1.25"
(31.8mm)
0.6" (15.2mm)
1.125"
(28.6mm)
1"
(25.4mm)
0.6" (15.2mm)
1"
(25.4mm)
1"
HubSat4Di Installation Guide
